PRODUCT DESCRIPTION
Features
Storage drawer
Stores cookware or kitchen accessories
Sealed burners
Keeps spills and crumbs contained so cleaning is always quick and easy
Fan convection
Includes a rear fan to distribute hot air throughout the oven for faster, more even baking
Closed-oven broiling
Delivers concentrated heat for broiling a variety of foods
Edge-to-edge cooktop with heavy-duty continuous cast-iron grates
Allows easy movement of cookware while providing even heat distribution with better heat retention
Incandescent interior lighting
See frozen pizzas, brownies and more with total clarity thanks to bright, focused interior lighting
Specifications
Total Capacity (cubic feet)
2.9 cu ft
Cooktop Burner Grate Color
Matte Black
Textured Steel Side Panels
Yes
Oven Door Features
Oven Window
Handle Color
Stainless Steel
Control Knobs
Stainless
Door Swing
Pull-Down
Color Appearance
Stainless Steel
Top Burner BTU Rating - Nat. Gas (000's BTU's)
(1) 15.0; (2) 9.5; (1) 5.0
Electrical Requirements
120V, 60Hz
Top Burner BTU Rating - LP (000's BTU's)
(1) 15.0; (2) 9.5; (1) 5.0
Amp Rating at 240V
15
Bake/Broiler BTU Rating - Nat. Gas (000's BTU's)
13.0
Bake/Broiler BTU Rating - LP (000's BTU's)
13.0
Hertz
60
Parts Warranty
Limited 1-year entire appliance
Labor Warranty
Limited 1-year entire appliance
Warranty Notes
See written warranty for full details
Air Fry Basket
Optional- JXAFTRAY1VSS
Optional Backguard
Included
LP Conversion Kit
Included
Net Weight
108 lb
Depth Without Handle
25.75 in
Height to Cooking Surface (in.)
36 1/4 +/- 1/4
Cabinet Width
24 in
Approximate Shipping Weight
121 lb
Overall Width
24 in
Overall Height
41 in
Overall Depth
28.125 in
Depth with Door Open
45.625 in
Oven Interior Dimensions (W x H x D) (in.)
19 x 15-3/8 x 17-1/8
Ignition System
Electronic
Storage Drawer Features
Removable Full-Width
Burner - Right Rear
5,000 BTU
Oven Interior
1 Incandescent Light Blue Gray
Oven Control Features
In-Oven Broiling
Oven Rack Features
2 Flat Nickel Racks
Burner - Left Rear
9,500 BTU
Oven Cleaning Type
Steam Clean
Product Type
Free-Standing Single Oven
Cooktop Type
Standard Grates
Cooktop Burner Grate Material
Heavy Duty Cast Iron
Fuel Type
Natural Gas
Control Location
Front
Number of Convection Oven Fans
1
Dishwasher Safe Knobs
Yes
Cooktop Burner Grate Features
Continuous Grates
Control Type
Rotary knobs
Burner - Left Front
9,500 BTU
Drawer Type
Storage
Sabbath Mode
Yes
Leveling System
4 Leveling Legs
Cooking Technology
Fan Convection
Configuration
Range with In Oven Broil
Oven Features
Clock/Timer
OU Certified
No
Oven Cooking Modes
Bake Broil Convection Bake
Cooktop Burner Type
Sealed
Valves (Degree of Turn)
270
Burner - Right Front
15,000 BTU
Cooktop Surface
Deep Drawn Stainless Steel
Oven Rack Positions (Single or Upper/Lower)
4
Edge-to-edge cooktop with heavy-duty continuous cast-iron grates
Easy clean
Modular backguard
Fan convection
Quick clean
Closed-oven broiling
Sealed burners
Perfect Match over-the-range microwave
Storage drawer
Incandescent interior lighting
GTIN
00084691829324
EAN
0084691829324
UPC
084691829324
Net Weight
108 lb
Depth Without Handle
25.75 in
Height to Cooking Surface (in.)
36 1/4 +/- 1/4
Cabinet Width
24 in
Approximate Shipping Weight
121 lb
Overall Width
24 in
Overall Height
41 in
Overall Depth
28.125 in
Depth with Door Open
45.625 in
Oven Interior Dimensions (W x H x D) (in.)
19 x 15-3/8 x 17-1/8
