PRODUCT DESCRIPTION
Specifications
Unit Capacity
40 Gallons
Installation
Free-Standing
Color Appearance
Gray
Operating Water Pressure
20-125 PSI (30-80 PSI recommended)
Hertz
60
Electrical Consumption - Lower Element
3600W
First Hour Rate (FHR)
67 Gallons
Energy Consumption (kWh/year)
773
Electrical Consumption - Upper Element
5500W
Electrical Circuit Required
240/208VAC 30A, 60Hz
Warranty Notes
See written warranty for full details
Parts Warranty
Limited 10-year tank and parts
Labor Warranty
Limited 1-year entire appliance
Operating Sound Level
41 dBA
Product Height (to top of water inlet/outlet connections)
59.5 in
Approximate Shipping Weight
194 lb
Overall Width
24 in
Overall Height
59.5 in
Product Height (to top of unit)
57.75 in
Net Weight
165 lb
Product Diameter
24 in
Overall Depth
24 in
Connection Sizes - Water Inlet (MNPT)
3/4"
Connection Sizes - Hot Water Outlet (MNPT)
3/4"
Control Type
Electronic LED Service Diagnostics Integrated
Demand Response Capable
Yes
Drain Valve
Left Side
UEF
3.8
Temp & Pressure Relief Valve
Right Side
Fuel Type
Electric
Operating Modes
Heat Pump High Demand/Boost Hybrid (Default Mode) Standard Electric
Electronic, Integrated Mixing Valve
Yes
Drain Valve Type
Brass
Temperature Setting Factory Default
120(degree) F
Product Type
Electric Heat Pump
WiFi Connect
Built-In
Water Connection Location
Top
Sensor
Leak Sensor Included (SPLK10N01A)
Communication
yes
Diagnostic Feedback
Filter, Lock, Standard Electric
Anode Rod
Magnesium Sensing
Renewable Air Filter
Top of Unit
Temperature Setting
100-140(degree) F Range
Connected Capabilities
Amazon Alexa Google Home
Up to 4.7x More Energy Efficiency
FlexCAPACITY
Homeowner Savings
Total Control with SmartHQ(TM)
Wireless Leak Detection with Automatic Water Shutoff
Dynamic Demand Response
Maximum Performance
Flexible & Easy Installation
Household Size
Five Operation Modes
10 Year Limited Warranty
Quiet Operation
Easy To Service
Sensing Anode Rod
Variable Speed Compressor
GTIN
00084691953470
EAN
0084691953470
UPC
084691953470
