PRODUCT DESCRIPTION
Features
Sensi-temp technology
Enjoy the same cooking power as a traditional coil with an added safety feature that meets the new UL858 Household Electric Ranges Standard for Safety
Removable full-width storage drawer
Large trays and other cookware can be conveniently stored for quick access
Specifications
Total Capacity (cubic feet)
5 cu ft
Oven Door Features
Big View Oven Window Glass Door
Handle
Designer Style
Textured Steel Side Panels
Yes
Control Knobs
Gloss Black
Handle Color
Stainless Steel
Color Appearance
Stainless Steel
KW Rating at 240V
10.2
Bake Wattage
2585W
Electrical Requirements
208/240V ; 60Hz ; 40A
Amp Rating at 208V
40
Broiler Wattage
3410W
KW Rating at 208V
7.6
Amp Rating at 240V
40
Hertz
60
Labor Warranty
Limited 1-year entire appliance
Parts Warranty
Limited 1-year entire appliance
Warranty Notes
See written warranty for full details
Net Weight
142 lb
Depth Without Handle
26.25 in
Oven Interior Dimensions (W x H x D) (in.)
23-3/4 x 19 x 18-1/2
Height to Cooking Surface (in.)
36 - 36 1/2
Depth with Door Open
46.25 in
Cabinet Width
30 in
Approximate Shipping Weight
162 lb
Overall Width
30 in
Overall Depth
28.75 in
Overall Height
47 in
Configuration
Range with Storage Drawer
Element - Right Front
8" 2400W Temp Limiting Coil
Oven Features
4-Pass Bake Element 4-Pass Broil Element
Removable One-Piece Drip Bowls
Black Porcelain Enameled
Cooking System
Traditional
Lift-Up Cooktop With Support Rods
Yes
Storage Drawer Features
Removable Full-Width
Fuel Type
Electric
Oven Interior
1 Incandescent Light
OU Certified
No
Oven Control Features
Audible Preheat Signal Auto Oven Shut-Off with Override Control Lock Capability Electronic Clock & Kitchen Timer Hi / Low Broil Oven "ON" Light
Cooktop Burner Type
Coil
Oven Rack Features
2 Oven Racks
Element - Left Front
6" 1250W Temp Limiting Coil
Oven Cleaning Type
Standard Clean
Product Type
Free-Standing Single Oven
Heating Element "ON" Indicator Light
Yes
Cooktop Type
Coil
Element - Left Rear
8" 2400W Temp Limiting Coil
Sabbath Mode
Yes
Element - Right Rear
6" 1250W Temp Limiting Coil
Cooktop Surface
One-Piece Upswept Porcelain-Enamel
Control Location
Backsplash
Drawer Type
Storage
Oven Rack Positions (Single or Upper/Lower)
6
Control Type
Digital Temperature Display Electronic Touchpads
Cooking Technology
Traditional
5.0 cu. ft. oven capacity
Standard clean oven
Sensi-temp technology
Electronic clock and timer
Removable full-width storage drawer
Dual-element Bake
GTIN
00084691906698
EAN
0084691906698
UPC
084691906698
Net Weight
142 lb
Depth Without Handle
26.25 in
Oven Interior Dimensions (W x H x D) (in.)
23-3/4 x 19 x 18-1/2
Height to Cooking Surface (in.)
36 - 36 1/2
Depth with Door Open
46.25 in
Cabinet Width
30 in
Approximate Shipping Weight
162 lb
Overall Width
30 in
Overall Depth
28.75 in
Overall Height
47 in
