PRODUCT DESCRIPTION
Features
5.0 cu. ft. oven capacity
Cook more dishes at once
Standard clean oven
Smooth surface and rounded corners make clean-up quick and easy
Sensi-temp technology
Enjoy the same cooking power as a traditional coil with an added safety feature that meets the new UL858 Household Electric Ranges Standard for Safety
Dual-element Bake
Upper and lower elements produce even heat and great results
Removable full-width storage drawer
Large trays and other cookware can be conveniently stored for quick access
Specifications
Parts
1 Year
Labor
1 Year
Overall Width
30 in
Overall Height
47 in
Overall Depth
29 in
Net Weight
130 lb
Depth Without Handle
26.25 in
Cabinet Width
30 in
Approximate Shipping Weight
150 lb
Depth with Door Open
46.25 in
Oven Interior Dimensions (W x H x D) (in.)
23-3/4 x 19 x 18-1/2
Height to Cooking Surface (in.)
36 - 36.5
Oven Interior Dimensions (W x H x D) (in.)
23-3/4 x 19 x 18-1/2
Width
30 in.
Height
47 in.
Length
29 in.
Weight
130 lbs.
Number of Boxes
1
Shipping Width
35 in.
Shipping Height
52 in.
Shipping Length
34 in.
Shipping Weight
170 lbs.
Total of Shipping Weight
170 lbs.
Source
Calculation
Cubic Feet Measurement
23.66 ft³
Dimensional Weight
294.17 lbs.
Total of Cubes
23.66 ft³
Total of Dimensional Weight
294.17 lbs.
Cooking System
Traditional
Storage Drawer Features
Removable Full-Width
Oven Interior
1 Incandescent Light
Oven Control Features
Oven "ON" Light
Lift-Up Cooktop With Support Rods
Yes
Oven Rack Features
2 Oven Racks
Element - Left Front
6" 1250W Temp Limiting Coil
Oven Cleaning Type
Standard Clean
Product Type
Free-Standing Single Oven
Heating Element "ON" Indicator Light
Yes
Cooktop Type
Coil
Fuel Type
Electric
Element - Right Front
8" 2400W Temp Limiting Coil
Control Location
Backsplash
Control Type
Rotary knobs
Drawer Type
Storage
Sabbath Mode
Yes
Element - Left Rear
8" 2400W Temp Limiting Coil
Cooking Technology
Traditional
Configuration
Range with Storage Drawer
Oven Features
4-Pass Bake Element
Removable One-Piece Drip Bowls
Chrome
OU Certified
No
Cooktop Burner Type
Coil
Element - Right Rear
6" 1250W Temp Limiting Coil
Cooktop Surface
One-Piece Upswept
Oven Rack Positions (Single or Upper/Lower)
6
Handle
Designer Style
Textured Steel Side Panels
Yes
Oven Door Features
Metal Door
Handle Color
White
Control Knobs
White
Color Appearance
White
Electrical Requirements
208/240V ; 60Hz ; 40A
Amp Rating at 208V
40
Broiler Wattage
3410W
Amp Rating at 240V
40
KW Rating at 240V
11.5
Bake Wattage
2585W
Hertz
60
KW Rating at 208V
8.8
Parts Warranty
Limited 1-year entire appliance
Labor Warranty
Limited 1-year entire appliance
Warranty Notes
See written warranty for full details
Total Capacity (cubic feet)
5.00 cu ft
5.0 cu. ft. oven capacity
Standard clean oven
Sensi-temp technology
Dual-element Bake
Removable full-width storage drawer
UPC
084691829126
