PRODUCT DESCRIPTION
Specifications
Overall Width
22 in
Overall Height
52.25 in
Product Height (to top of unit)
48.875 in
Overall Depth
22 in
Product Height (to top of water inlet/outlet connections)
50.375 in
Height to Gas Control
11.25 in
Approximate Shipping Weight
140 lb
Net Weight
133 lb
Product Diameter
22 in
Vent Size
3" Type B Vent
Connection Sizes - Water Inlet (MNPT)
3/4"
Connection Sizes - Hot Water Outlet (MNPT)
3/4"
FVIR Safety System
Prevents accidental ignition of flammable vapors
Vent
Atmospheric
Controls
LED Indicator
UEF
.64
Temp & Pressure Relief Valve
Yes
Height Description
Short
Fuel Type
Natural Gas
Pilot Light Window / Button
Yes
Configuration
Short
Drain Valve Type
Plastic
Product Type
Atmospheric Gas
Family Size
2-5 People
Bin Testing
High
Water Connection Location
Top
Overheat Protection
Dry Burning Protection
Gas Valve
Self Powered
Anode Rod
Magnesium
Temperature Setting
45-160° F Range
Altitude Rating
10,100 ft
Warranty Notes
See written warranty for full details
Parts Warranty
Limited 10-year tank and parts
Labor Warranty
Limited 1-year entire appliance
Burner BTU Size (k)
38
First Hour Delivery GPH
78 gal/h
Unit Capacity
40 Gallons
Color Appearance
Gray
Parts
10 Year
Labor
1 Year
Product Diameter
22 in
Vent Size
3" Type B Vent
Connection Sizes - Water Inlet (MNPT)
3/4"
Width
22 in.
Height
52.25 in.
Length
22 in.
Weight
133 lbs.
Number of Boxes
1
Shipping Width
27 in.
Shipping Height
57.25 in.
Shipping Length
27 in.
Shipping Weight
173 lbs.
Total of Shipping Weight
173 lbs.
Source
Calculation
Cubic Feet Measurement
14.63 ft³
Dimensional Weight
181.94 lbs.
Total of Cubes
14.63 ft³
Total of Dimensional Weight
181.94 lbs.
Household Size
Quick Recovery
Anode Rod
Magnesium
SmartShield ™ Safety System
Self-Diagnostic
Drain Valve
Easy Installation
Built-To-Last Warranty
FVIR Safety System
Yes
Vent
Atmospheric
Controls
LED Indicator
UEF
.64
Temp & Pressure Relief Valve
Yes
Height Description
Short
Fuel Type
Natural Gas
Pilot Light Window / Button
Yes
Configuration
Short
Drain Valve Type
Brass
Product Type
Atmospheric Gas
Family Size
2-5 People
Bin Testing
High
Water Connection Location
Top
Overheat Protection
Yes
Gas Valve
Self Powered
Altitude Rating
10100 ft
Temperature Setting
45-160(degree) F Range
UPC
084691862963
GTIN
00084691862963
EAN
0084691862963
Unit Capacity
40 Gallons
Color Appearance
Gray
Warranty Notes
See written warranty for full details
Parts Warranty
Limited 10-year tank and parts
Labor Warranty
Limited 1-year entire appliance
Burner BTU Size (k)
38
First Hour Rate (FHR)
78 Gallons
Product Height (to top of water inlet/outlet connections)
50.375 in
Height to Gas Control
11.25 in
Approximate Shipping Weight
140 lb
Overall Width
22 in
Overall Height
52.25 in
Product Height (to top of unit)
48.875 in
Net Weight
133 lb
Product Diameter
22 in
Overall Depth
22 in
Vent Size
2" or 3" Type B Vent
Connection Sizes - Water Inlet (MNPT)
3/4"
Connection Sizes - Hot Water Outlet (MNPT)
3/4"
