Real Capacity Get the most hot showers from the only water heater that holds a true 40 gallons of water (Compared to 40 gallon electric steel tank water heaters per DOE rated gallon capacity) Leading Performance Live comfortably with this best in class unit that delivers 66 gallons of hot water in the first hour (Measured through DOE First Hour Rating) Household Size Provide hot water for the whole family of 2 to 4 persons Quick Recovery Two 5500W heating elements quickly increase water temperature for hot water when you need it Inlet Tube Replenishes water from the bottom of the tank to maximize hot water delivery Easy Set Up Replace your old water heater quickly and easily using standard water and electrical connections Anode Rod Durable design offers long-lasting protection against corrosion Brass Drain Valve Rust-proof construction can be counted on to provide long-lasting service Adjustable Thermostat Change temperature to your desired setting
Specifications
capacity
1 item
Unit Capacity
40 Gallons
appearance
1 item
Color Appearance
Gray
power / ratings
9 items
Integrated Energy Factor
0.92
Heating - Electric - Heater Watts
5500/5500
Electrical Connection
Direct-Wire
Operating Water Pressure
20-125 PSI
Volts/Hertz
240V; 60Hz
First Hour Rate (FHR)
66 Gallons
Voltage (MAX)
240 V
Energy Consumption (kWh/year)
3531
Electrical Circuit Required
208V/240V 60 Hz Dedicated 30 Amp Min.
warranty
3 items
Warranty Notes
See written warranty for full details
Parts Warranty
Limited 8-year tank and parts
Labor Warranty
Limited 1-year entire appliance
weights & dimensions
10 items
Product Height (to top of water inlet/outlet connections)
52.875 in
Approximate Shipping Weight
133 lb
Overall Width
22 in
Overall Height
52.875 in
Product Height (to top of unit)
51.375 in
Net Weight
121 lb
Product Diameter
22 in
Overall Depth
22 in
Connection Sizes - Water Inlet (MNPT)
3/4"
Connection Sizes - Hot Water Outlet (MNPT)
3/4"
features
19 items
Control Type
Thermostat
Temp & Pressure Relief Valve
Yes
Height Description
Short
Heating Element
Copper
Fuel Type
Electric
Configuration
Short
Installation Location
Indoor
Operating Modes
Standard Electric
Rated Storage Capacity
40
Drain Valve Type
Brass
GPH Recovery @ 90 Degrees F
25.1
Mobile Home Compatible
No
Product Type
Electric Thermostat
Family Size
2-4 People
Water Connection Location
Top
Foam Insulation
Yes
Point of Use
No
Temperature Setting
90-150(degree) F Range Factory Default 120(degree) F
