PRODUCT DESCRIPTION
Specifications
Overall Width
27 in
Overall Height
32.75 in
Product Height (to top of unit)
32.75 in
Overall Depth
27 in
Product Height (to top of water inlet/outlet connections)
34.25 in
Approximate Shipping Weight
145 lb
Net Weight
135 lb
Product Diameter
27 in
Connection Sizes - Water Inlet (MNPT)
3/4"
Connection Sizes - Hot Water Outlet (MNPT)
3/4"
Width
27 in.
Height
32.75 in.
Length
27 in.
Weight
135 lbs.
Number of Boxes
1
Shipping Width
32 in.
Shipping Height
37.75 in.
Shipping Length
32 in.
Shipping Weight
175 lbs.
Total of Shipping Weight
175 lbs.
Source
Calculation
Cubic Feet Measurement
13.82 ft³
Dimensional Weight
171.76 lbs.
Total of Cubes
13.82 ft³
Total of Dimensional Weight
171.76 lbs.
Control Type
Thermostat
Temp & Pressure Relief Valve
Yes
Height Description
Low Boy with Top Port
Fuel Type
Electric
Configuration
Lowboy
Installation Location
Indoor
Operating Modes
Standard Electric
Rated Storage Capacity
36
GPH Recovery @ 90 Degrees F
25.1
Mobile Home Compatible
No
Temperature Setting Factory Default
120° F
Product Type
Electric Thermostat
Family Size
2-4 People
Water Connection Location
Top
Foam Insulation
Yes
Point of Use
No
Temperature Setting
90-150° F Range
Insulation Thickness
2.75 in
Drain Valve Type
Brass
Rated Capacity
36.0 gal
Integrated Energy Factor
0.92
Heating - Electric - Heater Watts
5500/5500
Electrical Connection
Direct-Wire
Operating Water Pressure
20-125 PSI
Volts/Hertz
240V; 60Hz
First Hour Rate (FHR)
61 Gallons
Voltage (MAX)
240 V
Electrical Circuit Required
208V/240V 60 Hz Dedicated 30 Amp Min.
Energy Consumption (kWh/year)
3531
Warranty Notes
See written warranty for full details
Parts Warranty
Limited 8-year tank and parts
Labor Warranty
Limited 1-year entire appliance
Unit Capacity
40 Gallons
Color Appearance
Gray
Lowboy
Household Size
Quick Recovery
Inlet Tube
Easy Set Up
Anode Rod
Adjustable Thermostat
Brass Drain Valve
Control Type
Thermostat
Temp & Pressure Relief Valve
Yes
Rated Capacity
36 gal
Height Description
Low Boy with Top Port
Fuel Type
Electric
Configuration
Lowboy
Installation Location
Indoor
Operating Modes
Standard Electric
Rated Storage Capacity
36
Drain Valve Type
Brass
GPH Recovery @ 90 Degrees F
25.1
Mobile Home Compatible
No
Product Type
Electric Thermostat
Family Size
2-4 People
Water Connection Location
Top
Foam Insulation
Yes
Point of Use
No
Temperature Setting
90-150(degree) F Range (BR)Factory Default 120(degree) F
Insulation Thickness
2.75 in
UPC
084691846048
GTIN
00084691846048
EAN
0084691846048
Unit Capacity
40 Gallons
Color Appearance
Gray
Integrated Energy Factor
0.92
Heating - Electric - Heater Watts
5500/5500
Electrical Connection
Direct-Wire
Operating Water Pressure
20-125 PSI
Volts/Hertz
240V; 60Hz
First Hour Rate (FHR)
61 Gallons
Voltage (MAX)
240 V
Energy Consumption (kWh/year)
3531
Electrical Circuit Required
208V/240V 60 Hz Dedicated 30 Amp Min.
Warranty Notes
See written warranty for full details
Parts Warranty
Limited 8-year tank and parts
Labor Warranty
Limited 1-year entire appliance
Product Height (to top of water inlet/outlet connections)
34.25 in
Approximate Shipping Weight
145 lb
Overall Width
27 in
Overall Height
32.75 in
Product Height (to top of unit)
32.75 in
Net Weight
135 lb
Product Diameter
27 in
Overall Depth
27 in
Connection Sizes - Water Inlet (MNPT)
3/4"
Connection Sizes - Hot Water Outlet (MNPT)
3/4"
