PRODUCT DESCRIPTION
Specifications
Overall Width
22 in
Overall Height
41.875 in
Product Height (to top of unit)
40.375 in
Overall Depth
22 in
Product Height (to top of water inlet/outlet connections)
41.875 in
Approximate Shipping Weight
111 lb
Net Weight
101 lb
Product Diameter
22 in
Connection Sizes - Water Inlet (MNPT)
3/4"
Connection Sizes - Hot Water Outlet (MNPT)
3/4"
Control Type
Thermostat
Temp & Pressure Relief Valve
Yes
Height Description
Short
Heating Element
Stainless steel
Fuel Type
Electric
Configuration
Short
Installation Location
Indoor
Operating Modes
Standard Electric
Rated Storage Capacity
30
Drain Valve Type
Brass
GPH Recovery @ 90 Degrees F
25.1
Mobile Home Compatible
No
Temperature Setting Factory Default
120° F
Product Type
Electric Thermostat
Family Size
1-3 People
Water Connection Location
Top
Foam Insulation
Yes
Point of Use
No
Temperature Setting
90-150° F Range
Insulation Thickness
2.75 in
Integrated Energy Factor
0.92
Heating - Electric - Heater Watts
5500/5500
Electrical Connection
Direct-Wire
Operating Water Pressure
20-125 PSI
Volts/Hertz
240V; 60Hz
First Hour Rate (FHR)
53 Gallons
Voltage (MAX)
240 V
Electrical Circuit Required
208V/240V 60 Hz Dedicated 30 Amp Min.
Energy Consumption (kWh/year)
3531
Warranty Notes
See written warranty for full details
Parts Warranty
Limited 10-year tank and parts
Labor Warranty
Limited 1-year entire appliance
Unit Capacity
30 Gallons
Color Appearance
Gray
Product Diameter
22 in
Connection Sizes - Water Inlet (MNPT)
3/4"
Width
22 in.
Height
41.88 in.
Length
22 in.
Weight
101 lbs.
Number of Boxes
1
Shipping Width
27 in.
Shipping Height
46.88 in.
Shipping Length
27 in.
Shipping Weight
141 lbs.
Total of Shipping Weight
141 lbs.
Source
Calculation
Cubic Feet Measurement
11.73 ft³
Dimensional Weight
145.81 lbs.
Total of Cubes
11.73 ft³
Total of Dimensional Weight
145.81 lbs.
Real Capacity
Leading Performance
Household Size
Quick Recovery
Stainless Steel Heating Elements
Inlet Tube
Brass Drain Valve
Easy Set Up
Adjustable Thermostat
Control Type
Thermostat
Temp & Pressure Relief Valve
Yes
Height Description
Short
Heating Element
Stainless steel
Fuel Type
Electric
Configuration
Short
Installation Location
Indoor
Operating Modes
Standard Electric
Rated Storage Capacity
30
Drain Valve Type
Brass
GPH Recovery @ 90 Degrees F
25.1
Mobile Home Compatible
No
Product Type
Electric Thermostat
Family Size
1-3 People
Water Connection Location
Top
Foam Insulation
Yes
Point of Use
No
Temperature Setting
90-150(degree) F Range (BR)Factory Default 120(degree) F
Insulation Thickness
2.75 in
UPC
084691846031
GTIN
00084691846031
EAN
0084691846031
Unit Capacity
30 Gallons
Color Appearance
Gray
Integrated Energy Factor
0.92
Heating - Electric - Heater Watts
5500/5500
Electrical Connection
Direct-Wire
Operating Water Pressure
20-125 PSI
Volts/Hertz
240V; 60Hz
First Hour Rate (FHR)
53 Gallons
Voltage (MAX)
240 V
Energy Consumption (kWh/year)
3531
Electrical Circuit Required
208V/240V 60 Hz Dedicated 30 Amp Min.
Warranty Notes
See written warranty for full details
Parts Warranty
Limited 10-year tank and parts
Labor Warranty
Limited 1-year entire appliance
Product Height (to top of water inlet/outlet connections)
41.875 in
Approximate Shipping Weight
111 lb
Overall Width
22 in
Overall Height
41.875 in
Product Height (to top of unit)
40.375 in
Net Weight
101 lb
Product Diameter
22 in
Overall Depth
22 in
Connection Sizes - Water Inlet (MNPT)
3/4"
Connection Sizes - Hot Water Outlet (MNPT)
3/4"
