PRODUCT DESCRIPTION
Specifications
Installation
Wall Mounted
Color Appearance
Diamond Gray
Power Rating-kW
18
First Hour Delivery GPH
120 gal/hr
Amps
75.0
Voltage (MAX)
240 V
Electrical Circuit Required
40 Amp (x2)
Electrical Requirements
240V ; 80A
Hertz
60
Parts Warranty
5-Year Replacement Return to Vendor
Warranty Notes
See written warranty for full details
Labor Warranty
No Warranty
Approximate Shipping Weight
15.2 lb
Overall Width
10.2 in
Overall Height
15.2 in
Product Height (to top of unit)
15.2 in
Net Weight
14.09 lb
Product Diameter
10.2 in
Overall Depth
3.7 in
Uniform Energy Factor (UEF)
>0.91
Flowrate (GPM) @ 47 F inlet
2.29
Flowrate (GPM) @ 37 F inlet
2
Flowrate (GPM) @ 77 F inlet
4.5
Flowrate (GPM) @ 62 F inlet
2.9
Min. operating pressure (psi)
25
Controls
Adjust degree Fahrenheit/Celsius Adjustable Temperature Digital Electronic Control
Max. operating pressure (psi)
150
Max: operating pressure (psi)
150
Fuel Type
Electric
Flowrate (GPM) @ 57 F inlet
2.59
Configuration
Space Saver
Installation Location
Indoor
Flowrate (GPM) @ 72 F inlet
3.79
Temperature adjustment amount (degree)
1
Activation Flowrate (GPM)
0.5
Temperature Setting Factory Default
105(degree) F
Product Type
Electric Tankless
Flowrate (GPM) @ 52 F inlet
2.4
Integrated Safety Devices
Flow sensor. High limit thermostat (on each heating element). Inlet Temperature Sensor. Material Rated for Ignition Containment. Outlet Temperature Sensor.
Maximum Outlet Temperature (F)
140
Water Connection Location
Bottom
Point of Use
Whole Home
Cold/hot water connections (inches)
3/4" Cold Water Inlet; 3/4" Hot Water Outlet
Flowrate (GPM) @ 67 F inlet
3.4
Temperature Setting
86-140(degree) F Range
Flowrate (GPM) @ 42 F inlet
2.09
Unlimited Hot Water on Demand
Whole Home Solution
Performance Up to 3.8 Gallons Per Minute (GPM)
Intuitive Design
Energy Efficient
Space Saver
Scale Reduction Technology
Self Modulating Technology
Easy Installation
Digital Temperature Control
Fahrenheit or Celsius
Warranty Length
GTIN
00084691856986
EAN
0084691856986
UPC
084691856986
