PRODUCT DESCRIPTION
Features
Designed & Assembled in America
Date of Manufacture – 2025 or later
R454B Refrigerant
Most environmentally friendly refrigerant on the market
Inverter Technology
Variable speed operation provides an advantage with shorter recovery time, improved efficiency, sound quality and dehumidification
Reverse Cycle Defrost
Advanced defrost capability allows for extended heat pump down to 0°F
Quick Installation
Complete installation for the interior makes installation 60% faster!
Insta-Platform
Eliminates the need for on-site customized platform construction saving time and money
Self-Contained Drainage System
Easy installation allows for simple chassis removal while leaving plumbing completely intact
Self-Aligning Lock-In-Place System
Insta-platform and VTAC are self-aligning with a lock-in-place system ensuring the unit is engaged with the plenum gasket
Ultra-Quit
Delivers quiet cooling power with smooth sound for a good night's sleep
Corrosion Protection
Exclusive rust-proof base pan and bulkhead, double painted compressor, stainless steel end brackets, and painted motor surfaces provide another level of corrosion protection
On-Board Diagnostics
Electronic controls give clear and fast diagnostic data and fault codes, for fast and easy resolution
SmartHQ™ WIFI Capability
On-board Wifi SmartHQ™ Management gives property managers the ability to monitor multiple units remotely, enhancing guest experience
Specifications
Cooling BTU (230 / 208V)
22400
COP2 @ 47F
2.8
EER
8.9
HSPF2 Rating
7.7
Heat Pump COP2@17F (Nominal/Max)
2 (230V Performance Data Listed)
Heating BTU @17F (Nominal/Max)
17000
Heating BTU Range @ 47F
5,000-23,000
Makeup Air CFM
30-70 (no filter) 20-50 (with MERV13 filter kit)
Refrigerant Type
R454B
SEER2
16
Sensible Heat Ratio
0.7
Zoneline Features
Self-Aligning, Lock-In-Place System
Approximate Shipping Weight
150 lb
Net Weight
137 lb
Cooling - Amperes
10.9
Cooling - Watts
2430
Cooling BTUH Range (@95F Outdoor)
5000 - 24,000
Cooling BTUH (MAX - 115F)
20200
Cooling BTUH (MAX - 75F)
27800
Heat Pump - Amps
4.4
Heat Pump - Watts
925
Rated Heat Pump BTU
21500
Voltage (MAX)
230 V
Voltage (MIN)
208 V
Labor Warranty
Limited 5-year sealed system
Parts Warranty
5 year limited parts warranty
Warranty Notes
See written warranty for full details
Designed & Assembled in America
R454B Refrigerant
Inverter Technology
Reverse Cycle Defrost
Quick Installation
Insta-Platform
Self-Contained Drainage System
Self-Aligning Lock-In-Place System
Ultra-Quit
Corrosion Protection
On-Board Diagnostics
SmartHQ™ WIFI Capability
UPC
084691980117
