PRODUCT DESCRIPTION
Specifications
Heating - Electric - BTUH - AHAM - 1R
10600/8600
Dehumidification (pts./hr.)
3.4/3.4
Installation
Wall Mounted
Color Appearance
Soft Gray
Warranty Notes
See written warranty for full details
Labor Warranty
5-year sealed refrigerating system Full 2-year entire appliance
Parts Warranty
Limited 2-year entire appliance Limited 5-year sealed refrigerating system
Hertz
60
Volts/Hertz
230V-208V/60Hz
Rated Heat Pump BTU
8500/8300
Cooling Rated Capacity BTU/Hr
12,000 Btu
Voltage/Hertz/Phase
230-208/60/1
Voltage (MIN)
208 V
CEER
9.5/9.5
Voltage (MAX)
230 V
Heating - Electric - Heater Amps
15.0/13.5
Wall Case
RAB46/47/48/26 Required At Additional Cost
Overall Width
26 in
Approximate Shipping Weight
94 lb
Depth to Louvers
5 in
Overall Height (Excludes Sleeve)
14.875 in
Overall Height
15.625 in
Overall Depth (Excludes Sleeve)
19.90625 in
Overall Depth
21.8125 in
Overall Width (Excludes Sleeve)
24.8125 in
Net Weight
92.2 lb
Louver Style
6-Way
Control Type
Electronic
Fan Speed Selections
3 Cooling 3 Fan Only Variable
Optional Grill
RAG13/RAG13A/RAG14E
Product Type
Built-In
Refrigerant Type
R32
Air Discharge
Over / Under
Filter Type
Rigid Frame Tilt-Out Washable
Style
Thru-Wall
Chassis Type
Slide-In
Plug Type
Perpendicular/Right Angle LCDI
Heating - Electric - Input Watts
3450/2821
WiFi Connect
Built-In
Remote Control
Yes
Thermostat Type
Electronic Digital
Temperature Range
60->85 F
LCDI / AFCI power cord
LCDI
Cord Length
68"
Cooling Capacity Range BTU/Hr
6,100 - 12,400 Btu
Rotary Compressor
Yes
Digital Time Temp Display
Yes
Outdoor Vent / Exhaust
Yes
Unit Type
Heat / Cool Unit
Room Air Conditioner Features
Batteries Included Improved Corrosion Package Remote Control Smart Fan Switch
GTIN
00084691980148
EAN
0084691980148
UPC
084691980148
