PRODUCT DESCRIPTION
Features
Extra Wide Store-More(TM) Storage Drawer
Redesigned to be even wider - allowing you to store any unused oven racks, baking trays and more!
Even Baking Technology
Designed to deliver even baking results, every time.
Continuous Edge-to-Edge Grates
Moving heavy pots and pans across the cooktop is easier with continuous edge-to-edge grates.
Quick Boil
Experience faster boil times and more powerful cooking with the 18,000 BTU burner.
Five Burner Cooktop
Designed to meet all of your cooking needs with a 5,000-BTU simmer burner, 10,000-BTU center oval burner, and 18,000-BTU Quick Boil Burner.
30-Minute Steam Clean
Specifications
Cooking Surface Type
Gas
Grate Material
Cast Iron
Grate Quantity
3
Grate Style
Continuous
Total Number of Burners
5
Right Front Element Burner
18000 BTU
Right Rear Element Burner
5000 BTU
Left Front Element Burner
14000 BTU
Left Rear Element Burner
10000 BTU
Center Rear Element Burner
10000 BTU
Bake
Yes
Broil
Yes
Clock
Yes
Cook Time
Yes
Delay Clean
Yes
Delay Start
Yes
Keep Warm
Yes
Kitchen Timer
Yes
Light
Yes
Lockout
Yes
Off
Yes
Oven Light
Yes
Set Clock
Yes
Start
Yes
Steam Clean
Yes
Temperature Display
Yes
Timer On / Off
Yes
Up / Down Arrow
Yes
User Preferences
Yes
Adjustable Volume Feedback
Yes
Change between Continuous Bake Setting or 12-Hour Energy Saving Feature
Yes
Delayed Bake
Yes
Program Fahrenheit or Celsius
Yes
Bake Element
17000 BTU
Broil Element
1400 Watts
Broil Element Pass
6
Number of Rack Positions
6
Oven Interior Color
Midnight Black
Oven Light Quantity
1
Oven Light Type
Halogen
Oven Light Watts
40 Watts
Rack Position Type
Embossed
Rack Type 1
Flat
Rack Type 1 Quantity
2
Drawer Handle Style
Integrated
Drawer Type
Storage
Control Lock
Yes
Control Location
Rear
Display Interface Color
White
Display Type
Membrane
Minimum Height
46 3/4"
Maximum Height
47 3/4"
Width
30"
Depth
26"
Depth With Door 90(degree) Open
47 5/16"
Depth With Handle
28 1/2"
Oven Interior Height
17 5/8"
Oven Interior Width
25 3/16"
Oven Interior Depth
19 7/8"
Oven Capacity
5.1 Cu. Ft.
Minimum Circuit Required
12 Amps
Voltage Rating
120 V
Adjustable Leveling Legs
Yes
Power Cord Included
Yes
Product Weight
170 lbs
Prop 65 Label
Yes
Warranty - Labor
1 Year
Warranty - Parts
1 Year
CSA Listed
Yes
Product Line
Gas Range
Power Type
NG
Size
30"
Installation Type
Free-Standing
Factory
Springfield
Color
White
GTIN
00012505514838
EAN
0012505514838
UPC
012505514838
Quick Boil
Five Burner Cooktop
Even Baking Technology
30-Minute Steam Clean
Continuous Edge-to-Edge Grates
Extra Wide Store-More(TM) Storage Drawer
5.1 Cu. Ft. Oven Capacity
Dishwasher Safe Burner Caps
Hidden Bake Element
Proudly Assembled in the USA
