Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
Fracci n arancelaria
8414600100.00
SHIPPING WEIGHT (kg)
37.20
CARTON LENGHT (mm)
1020.00
CARTON HEIGHT (mm)
818.00
SHIPPING WEIGHT (lb)
82.01
COUNTRY OF MANUFACTURE
MX
INTENDED APPROVED USE
Residential use
Type of Ventilation
Vented
HOODS FEATURES
Hush system, Heat guard, Grease collectors, Professional performance, Seamless look
EXHAUST VERSION
Ducted Only
EXHAUST LOCATION
Top Only
RECTANGULAR DUCTH HEIGHT
NA
RECTANGULAR DUCT WIDTH
NA
LIGHTING
LED 2 x 6.5 ww 3000 KK
GREASE FILTER TYPE
Dishwasher-Safe, Professional Stainless Steel Angled Baffle Filter
DISHWASHERSAFE FILTER
YES
FILTER MATERIAL
Stainless Steel
BLOWER TYPE
Interior Unit
CONTROL TYPE
Fully Retractable Rotating Knobs w/ Blue Backlighting
RECIRCULATION KIT NEEDED
NO
DIMENSIONS (CM)
90 x 61 x 76 - 137
DIMENSIONS (INCH)
36" W x 24 D x 30 - 54 H
Overall Height - Top to Bottom
30
Overall Width - Side to Side2
36"
Overall Depth - Front to Back
24
Min - Max Compatible Ceiling Height (Cover electronic cooking)
7'6" - 10'6"
Min - Max Compatible Ceiling Height ( Cover gas cooking)
8'0" - 10'6"
Minimum Height Above Cooktop (ELECTRIC)
24
Minimum Height Above Cooktop (GAS)
30
Maximum Height Above Cooktop
36"
Chimney Width - Side to Side
13 3/16"
Chimney Depth - Front to Back
10 5/8"
Chimney Height - Top to Bottom
Min: 30" - Max: 54"
Long Life Recirculating Carbon Filter
NA
Recirculation (400 CFM) 2 round carbon filters
NA
Recirculation (400 CFM) Contains 6 deflector & 3 carbon filters
NA
Recirculation (600 CFM) Contains 6 deflector, 3 flat carbon filters & clips
NA
Recirculation (600 CFM) Contains 6 deflector & 2 carbon filters
NA
Recirculation (600 CFM) 2 round carbon filters
NA
Recirculation (600 CFM) 4 round carbon filters
KIT0192765
Recirculation (600 CFM) 6 round carbon filters
NA
Recirculation (600 CFM) 6 round Deflector
KIT0192767
Recirculation (1200 CFM) 4 round deflector
NA
Recirculation (1200 CFM) 4 round carbon filters
NA
Recirculation (1200 CFM) (8 round deflector)
NA
Long Chimney Ext/Chimney extension
KIT0146881
Chimney extension Can reach 8 8 - 12 4 (ducted), 9 0 -12 8 (recirculating)
NA
Chimney extension Can reach 7 9 - 10 9 (ducted), 8 1 -11 1 (recirculating)
NA
Chimney extension Reaches ceiling heights 8 5 -12 1 (ducted), 9 1 -12 5 (recirculating)
NA
Chimney extension Reaches ceiling heights 7 5 -10 3 (ducted), 8 2 -10 11 (recirculating)
NA
Long Chimney Extension(6 )
NA
Long Chimney Extension(11 )
NA
Long Chimney Extension(12 )
NA
Long Chimney Extension(13 )
NA
Long Chimney Extension (6 with grates)
NA
TRANSITION REDUCER KIT 10 round down to 8 round - attaches to 10 round transition
-
RECIRCULATION DUCT COVERS
KIT0184907
RECIRCULATION DEFLECTOR
NA
CFM REDUCTION KIT
KIT0185752
EXTERNAL BLOWER
KIT0153054
INLINE BLOWER SHELL KIT (600 CFM)
KIT0205342
INLINE BLOWER SHELL KIT (1200 CFM)
KIT0179549
EXTERNAL BLOWER SHELL KIT
KIT0179547
HIGH CEILING EXTENSION KIT
-
Duct cover extension 6
NA
Duct cover extension 18
NA
COMERCIAL USE APPROVED
NO
VENTILATION DIRECTION
HORIZONTAL
FITLER INDICATOR LIGHT
NO
