PRODUCT DESCRIPTION
Specifications
Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
SHIPPING WEIGHT (kg)
39.00
NET WEIGHT (kg)
29.00
CARTON LENGHT (mm)
1138.00
CARTON HEIGHT (mm)
721.00
CARTON WIDTH (mm)
895.00
VOLUMEN (M3)
0.57
SHIPPING WEIGHT
85.98
NET WEIGHT
63.93
CARTON LENGHT
44.80
CARTON HEIGHT
28.39
CARTON WIDTH
35.24
COUNTRY OF MANUFACTURE
MX
QTY PACKAGE
1.00
INTENDED APPROVED USE
Residential use
Finish
Matte Black + Mirror Finish Stainless Steel
Color
black matte
Type of Ventilation
Convertible
HOODS FEATURES
Hush system, Heat guard, Grease collectors, Seamless look, Professional performance, Elica easy mounting, Rear outlet installation
WIDTH (IN)
48"
WIDTH (CM)
120.00
AIRFLOW (M3/H)
1020/2040
CFM (MAX)
600/1200
db (min)
36.00
db (max)
56 / 59
SONES
1.7-7.0 / 1.7-8.5
EXHAUST VERSION
Convertible with Kit
EXHAUST SIZE
Round 6" / Round 8"
DUCT SHAPE
Round
EXHAUST LOCATION
Top or Rear
RECTANGULAR DUCTH HEIGHT
NA
RECTANGULAR DUCT WIDTH
NA
Round duct diameter
6"/8"
ELECTRIC (VOLTS)
120 V/60 Hz
AMPERAGE
NA
HERTZ
NA
WATTS
NA
LIGHTING
NA
BULB TYPE
NA
BULB INCLUDED
NA
NUMBER OF LIGHTS
NA
BULB WATTS
NA
GREASE FILTER TYPE
NA
DISHWASHERSAFE FILTER
NA
FILTER MATERIAL
NA
BLOWER TYPE
Needs Pairing with Arezzo Insert
CONTROL TYPE
Fully Retractable Rotating Knobs w/ Blue Backlighting
SPEED CONTROL
YES
NUMBER OF SPEEDS
4.00
REMOTE CONTROL
NO
POWER SOURCE
NA
OUTDOOR USE
NO
SMUDGE RESISTANT
NO
RECIRCULATION KIT NEEDED
NO
CFM REDUCTION
NA
DIMENSIONS
120 x 76 x 62
DIMENSIONSinches
ADJUSTABLE HEIGHT
NO
Minimum Overall Height - Top to Bottom
30
Maximum Overall Height - Top to Bottom
30
Overall Height - Top to Bottom
30
Overall Width - Side to Side2
48
Overall Depth - Front to Back
23 15/
Hood Height
30
Minimum Compatible Ceiling Height
NA
Maximum Compatible Ceiling Height
NA
Minimum Height Above Cooktop (ELECTRIC)
24
Minimum Height Above Cooktop (GAS)
30
Maximum Height Above Cooktop
30"
Chimney Width - Side to Side
NA
Chimney Depth - Front to Back
NA
Chimney Height - Top to Bottom
NA
RECIRCULATION KIT NUMBER
NA
CHIMNEY EXTENSION NUMBER
KIT0203030/KIT0203029
TELESCOPIC DUCT COVER
-
DUCT TRANSITION
-
TRANSITION REDUCER KIT
-
BACKDRAFT DAMPER
-
NON RETURN VALVE
-
UPGRADE FILTER
-
CFM REDUCTION KIT
-
BACKSPLASH KIT
-
INTERNAL BLOWER
-
INLINE BLOWER
-
EXTERNAL BLOWER
-
INLINE BLOWER SHELL KIT
-
EXTERNAL BLOWER SHELL KIT
-
HEAT LAMPS
-
SPACER/LINER
-
WALL MOUNT BRACKET
-
HIGH CEILING EXTENSION KIT
-
REMOTE CONTROL KIT
-
cUL listed
YES
UL listed
YES
AHAM verified
YES
TITLE 24
YES
Prop65Disclosure
YES
ENERGY STAR
NO
WIFI CAPABLE
NO
COMERCIAL USE APPROVED
NO
ADA COMPLIANT
NO
APP CAPABLE
NO
VENTILATION DIRECTION
HORIZONTAL
SMART COMPATIBLE
NO
FITLER INDICATOR LIGHT
NO
HEAT SENSOR
YES
CHAROCAL FILTER
NO
CERTIFICADO NOM
NA
DIMENSIONS inches
48" x 30" x 24 5/16"
Prop65 Disclosure
YES
GTIN
00190603006650
EAN
0190603006650
UPC
190603006650
Hush system
Heat guard
Grease collectors
Seamless look
Professional performance
Elica easy mounting
Rear outlet installation
