PRODUCT DESCRIPTION
Specifications
Width
30 , 36
Sones
5.9
Extraction capacity
400 CFM
Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
SHIPPING WEIGHT (kg)
22.00
NET WEIGHT (kg)
17.00
CARTON LENGHT (mm)
870.00
CARTON HEIGHT (mm)
673.00
CARTON WIDTH (mm)
458.00
VOLUMEN (M3)
0.20
SHIPPING WEIGHT
48.50
NET WEIGHT
37.52
CARTON LENGHT
34.25
CARTON HEIGHT
26.50
CARTON WIDTH
18.03
COUNTRY OF MANUFACTURE
MX
QTY PACKAGE
1.00
INTENDED APPROVED USE
Residential use
Finish
Stainless Steel
Color
inox
Type of Ventilation
Convertible
HOODS FEATURES
3x layer mesh, Led light, CFM reduction system
WIDTH (IN)
30"
WIDTH (CM)
76.00
AIRFLOW (M3/H)
680.00
CFM (MAX)
400.00
db (min)
15.00
db (max)
53.00
SONES
0.4 - 5.9
EXHAUST VERSION
Convertible with Kit
EXHAUST SIZE
Round 6"
DUCT SHAPE
Round
EXHAUST LOCATION
Top Only
RECTANGULAR DUCTH HEIGHT
NA
RECTANGULAR DUCT WIDTH
NA
Round duct diameter
6"
ELECTRIC (VOLTS)
120 V/60 Hz
AMPERAGE
2.5 A
HERTZ
60.00
WATTS
265.00
LIGHTING
LED 2 x 2.1 ww 3000 KK
BULB TYPE
LED
BULB INCLUDED
YES
NUMBER OF LIGHTS
2.00
BULB WATTS
2.10
KELVINS
3000.00
GREASE FILTER TYPE
Dishwasher-Safe, Anodized Aluminum Mesh Filter
DISHWASHERSAFE FILTER
YES
FILTER MATERIAL
Aluminum Mesh
BLOWER TYPE
Interior Unit
CONTROL TYPE
Electronic Touch Controls with Adjustable Color Backlight
SPEED CONTROL
YES
NUMBER OF SPEEDS
4.00
REMOTE CONTROL
NO
POWER SOURCE
Hardwired
OUTDOOR USE
NO
SMUDGE RESISTANT
NO
RECIRCULATION KIT NEEDED
YES
CFM REDUCTION
YES
DIMENSIONS
76 cm x 69 cm x76
DIMENSIONSinches
ADJUSTABLE HEIGHT
YES
Minimum Overall Height - Top to Bottom
20 3/4"
Maximum Overall Height - Top to Bottom
35"
Overall Height - Top to Bottom
20 3/4"-35"
Overall Width - Side to Side2
30"
Overall Depth - Front to Back
19 11/16"
Hood Height
1 5/8"
Minimum Compatible Ceiling Height
6'11"
Maximum Compatible Ceiling Height
8'11"
Minimum Height Above Cooktop (ELECTRIC)
= 24
Minimum Height Above Cooktop (GAS)
= 30
Maximum Height Above Cooktop
36"
Chimney Width - Side to Side
13"
Chimney Depth - Front to Back
10 3/4"
Chimney Height - Top to Bottom
33 3/8
RECIRCULATION KIT NUMBER
KIT0184663
CHIMNEY EXTENSION NUMBER
KIT02785/KIT01935
TELESCOPIC DUCT COVER
-
DUCT TRANSITION
-
TRANSITION REDUCER KIT
-
BACKDRAFT DAMPER
-
NON RETURN VALVE
-
UPGRADE FILTER
GF04YB
CFM REDUCTION KIT
-
BACKSPLASH KIT
-
INTERNAL BLOWER
-
INLINE BLOWER
-
EXTERNAL BLOWER
-
INLINE BLOWER SHELL KIT
-
EXTERNAL BLOWER SHELL KIT
-
HEAT LAMPS
-
SPACER/LINER
-
WALL MOUNT BRACKET
-
HIGH CEILING EXTENSION KIT
-
REMOTE CONTROL KIT
-
cUL listed
YES
UL listed
YES
AHAM verified
YES
TITLE 24
YES
Prop65Disclosure
YES
ENERGY STAR
NO
WIFI CAPABLE
NO
COMERCIAL USE APPROVED
NO
ADA COMPLIANT
NO
APP CAPABLE
NO
VENTILATION DIRECTION
HORIZONTAL
SMART COMPATIBLE
NO
FITLER INDICATOR LIGHT
NO
HEAT SENSOR
NO
CHAROCAL FILTER
YES
VERSION ADVANCES
Button change
CERTIFICADO NOM
NA
DIMENSIONS inches
30 x 19 11/16" x 20 3/4"
Prop65 Disclosure
YES
GTIN
00190603004441
EAN
0190603004441
UPC
190603004441
3x layer mesh
Led light
CFM reduction system
