PRODUCT DESCRIPTION
Specifications
Width
30 , 36
Sones
7
Extraction capacity
600 CFM
Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
SHIPPING WEIGHT (kg)
53.00
NET WEIGHT (kg)
39.00
CARTON LENGHT (mm)
856.00
CARTON HEIGHT (mm)
409.00
CARTON WIDTH (mm)
889.00
VOLUMEN (M3)
0.30
SHIPPING WEIGHT
116.84
NET WEIGHT
85.98
CARTON LENGHT
33.70
CARTON HEIGHT
16.10
CARTON WIDTH
35.00
COUNTRY OF MANUFACTURE
MX
QTY PACKAGE
1.00
INTENDED APPROVED USE
Residential use
Finish
Stainless Steel
Color
inox
Type of Ventilation
Non-Vented
HOODS FEATURES
Perimeter aspiration, Top performance
WIDTH (IN)
30"
WIDTH (CM)
76.00
AIRFLOW (M3/H)
1020.00
CFM (MAX)
600.00
db (min)
36.00
db (max)
55.00
SONES
1.7 - 6.8
EXHAUST VERSION
Ducted Only
EXHAUST SIZE
Round 6"
DUCT SHAPE
Round
EXHAUST LOCATION
Side
RECTANGULAR DUCTH HEIGHT
NA
RECTANGULAR DUCT WIDTH
NA
Round duct diameter
6"
ELECTRIC (VOLTS)
120 V/60 Hz
AMPERAGE
3.6 A
HERTZ
60.00
WATTS
550.00
LIGHTING
NA
BULB TYPE
NA
BULB INCLUDED
NA
NUMBER OF LIGHTS
NA
BULB WATTS
NA
KELVINS
NA
GREASE FILTER TYPE
Dishwasher-Safe, Anodized Aluminum Mesh Filter + Perimeter Aspiration
DISHWASHERSAFE FILTER
YES
FILTER MATERIAL
Aluminum Mesh
BLOWER TYPE
Interior Unit
CONTROL TYPE
Electronic Rotating Disc
SPEED CONTROL
YES
NUMBER OF SPEEDS
3 + booster
REMOTE CONTROL
NO
POWER SOURCE
Hardwired
OUTDOOR USE
NO
SMUDGE RESISTANT
NO
RECIRCULATION KIT NEEDED
NO
CFM REDUCTION
No
DIMENSIONS
76 x 32 x 35
DIMENSIONSinches
ADJUSTABLE HEIGHT
NO
Minimum Overall Height - Top to Bottom
14"
Maximum Overall Height - Top to Bottom
14"
Overall Height - Top to Bottom
14"
Overall Width - Side to Side2
30"
Overall Depth - Front to Back
12 1/2
Hood Height
14"
Minimum Compatible Ceiling Height
NA
Maximum Compatible Ceiling Height
NA
Minimum Height Above Cooktop (ELECTRIC)
= 24
Minimum Height Above Cooktop (GAS)
= 30
Maximum Height Above Cooktop
36"
Chimney Width - Side to Side
NA
Chimney Depth - Front to Back
NA
Chimney Height - Top to Bottom
NA
RECIRCULATION KIT NUMBER
KIT02728
CHIMNEY EXTENSION NUMBER
NA
TELESCOPIC DUCT COVER
-
DUCT TRANSITION
-
TRANSITION REDUCER KIT
-
BACKDRAFT DAMPER
-
NON RETURN VALVE
-
UPGRADE FILTER
-
CFM REDUCTION KIT
-
BACKSPLASH KIT
-
INTERNAL BLOWER
-
INLINE BLOWER
-
EXTERNAL BLOWER
-
INLINE BLOWER SHELL KIT
-
EXTERNAL BLOWER SHELL KIT
-
HEAT LAMPS
-
SPACER/LINER
-
WALL MOUNT BRACKET
-
HIGH CEILING EXTENSION KIT
-
REMOTE CONTROL KIT
-
cUL listed
YES
UL listed
YES
AHAM verified
YES
TITLE 24
YES
Prop65Disclosure
YES
ENERGY STAR
NO
WIFI CAPABLE
NO
COMERCIAL USE APPROVED
NO
ADA COMPLIANT
NO
APP CAPABLE
NO
VENTILATION DIRECTION
DOWNDRAFT
SMART COMPATIBLE
NO
FITLER INDICATOR LIGHT
NO
HEAT SENSOR
NO
CHAROCAL FILTER
NO
CERTIFICADO NOM
NA
DIMENSIONS inches
30" x 12 1/2 x 14"
Prop65 Disclosure
YES
Perimeter aspiration
Top performance
