PRODUCT DESCRIPTION
Specifications
Width
28 , 34
Sones
7
Extraction capacity
600 CFM
Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
SHIPPING WEIGHT (kg)
14.70
NET WEIGHT (kg)
10.60
CARTON LENGHT (mm)
841.00
CARTON HEIGHT (mm)
409.00
CARTON WIDTH (mm)
389.00
VOLUMEN (M3)
0.13
SHIPPING WEIGHT
32.41
NET WEIGHT
23.37
CARTON LENGHT
33.11
CARTON HEIGHT
16.10
CARTON WIDTH
15.31
COUNTRY OF MANUFACTURE
MX
QTY PACKAGE
1.00
INTENDED APPROVED USE
Residential use
Finish
Stainless Steel
Color
inox
Type of Ventilation
Convertible
HOODS FEATURES
Semi baffle filter, Hush system, Led light, Top performance
WIDTH (IN)
28"
WIDTH (CM)
72.00
AIRFLOW (M3/H)
1020.00
CFM (MAX)
600.00
db (min)
35.65
db (max)
55.00
SONES
1.7 - 6.8
EXHAUST VERSION
Convertible with Kit
EXHAUST SIZE
Round 6"
DUCT SHAPE
Round
EXHAUST LOCATION
Top Only
RECTANGULAR DUCTH HEIGHT
NA
RECTANGULAR DUCT WIDTH
NA
Round duct diameter
6"
ELECTRIC (VOLTS)
120 V/60 Hz
AMPERAGE
2.2 A
HERTZ
60.00
WATTS
455.00
LIGHTING
LED 2 x 2.1 ww 4000 KK
BULB TYPE
LED
BULB INCLUDED
YES
NUMBER OF LIGHTS
2.00
BULB WATTS
2.10
KELVINS
4000.00
GREASE FILTER TYPE
Dishwasher-Safe, Stainless Steel Baffle Slot Filter
DISHWASHERSAFE FILTER
YES
FILTER MATERIAL
Stainless Steel
BLOWER TYPE
Interior Unit
CONTROL TYPE
Stainless Steel Push Button
SPEED CONTROL
YES
NUMBER OF SPEEDS
3.00
REMOTE CONTROL
NO
POWER SOURCE
Power Cord
OUTDOOR USE
NO
SMUDGE RESISTANT
NO
RECIRCULATION KIT NEEDED
YES
CFM REDUCTION
Yes w/kit
DIMENSIONS
70 x 27 x 37
DIMENSIONS inches
28 1/4" x 10 3/4 x 9 1/2
ADJUSTABLE HEIGHT
NO
Minimum Overall Height - Top to Bottom
9 1/2
Maximum Overall Height - Top to Bottom
9 1/2
Overall Height - Top to Bottom
9 1/2
Overall Width - Side to Side2
28 1/4"
Overall Depth - Front to Back
10 3/4
Hood Height
9 1/2
Minimum Compatible Ceiling Height
NA
Maximum Compatible Ceiling Height
NA
Minimum Height Above Cooktop
30"
Maximum Height Above Cooktop
36"
Chimney Width - Side to Side
NA
Chimney Depth - Front to Back
NA
Chimney Height - Top to Bottom
NA
STYLE
Modern
RECIRCULATION KIT NUMBER
KIT02770
CHIMNEY EXTENSION NUMBER
NA
TELESCOPIC DUCT COVER
-
DUCT TRANSITION
-
TRANSITION REDUCER KIT
-
BACKDRAFT DAMPER
-
NON RETURN VALVE
-
UPGRADE FILTER
-
CFM REDUCTION KIT
KIT0175561
BACKSPLASH KIT
-
INTERNAL BLOWER
-
INLINE BLOWER
-
EXTERNAL BLOWER
-
INLINE BLOWER SHELL KIT
-
EXTERNAL BLOWER SHELL KIT
-
HEAT LAMPS
-
SPACER/LINER
KIT02773/KIT02774
WALL MOUNT BRACKET
-
HIGH CEILING EXTENSION KIT
-
REMOTE CONTROL KIT
-
cUL listed
YES
UL listed
YES
AHAM verified
YES
TITLE 24
YES
Prop65 Disclosure
YES
ENERGY STAR
NO
WIFI CAPABLE
NO
COMERCIAL USE APPROVED
NO
ADA COMPLIANT
NO
APP CAPABLE
NO
VENTILATION DIRECTION
HORIZONTAL
SMART COMPATIBLE
NO
FITLER INDICATOR LIGHT
NO
HEAT SENSOR
NO
CHAROCAL FILTER
YES
CERTIFICADO NOM
Activo
GTIN
00190603002089
EAN
0190603002089
UPC
190603002089
Semi baffle filter
Hush system
Led light
Top performance
