PRODUCT DESCRIPTION
Specifications
Width
36 , 48
Sones
Min 7 Max 8.2
Extraction capacity
600 CFM / 1200 CFM
Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
SHIPPING WEIGHT (kg)
37.00
NET WEIGHT (kg)
27.90
CARTON LENGHT (mm)
1049.50
CARTON HEIGHT (mm)
1013.50
CARTON WIDTH (mm)
699.50
VOLUMEN (M3)
0.70
SHIPPING WEIGHT
81.57
NET WEIGHT
61.51
CARTON LENGHT
41.32
CARTON HEIGHT
39.90
CARTON WIDTH
27.54
COUNTRY OF MANUFACTURE
MX
QTY PACKAGE
1.00
INTENDED APPROVED USE
Residential use
Finish
Stainless Steel
Color
inox
Type of Ventilation
Vented
HOODS FEATURES
Hush system, Heat guard, Grease collectors, Seamless look Professional performance, Elica easy mounting, Rear outlet installation
WIDTH (IN)
36"
WIDTH (CM)
90.00
AIRFLOW (M3/H)
1020/2040
CFM (MAX)
600/1200
db (min)
36.00
db (max)
56 / 59
SONES
1.7-7.0 / 1.7-8.5
EXHAUST VERSION
Convertible with Kit
EXHAUST SIZE
Round 6" / Round 8"
DUCT SHAPE
NA
EXHAUST LOCATION
Top Only
RECTANGULAR DUCTH HEIGHT
NA
RECTANGULAR DUCT WIDTH
NA
Round duct diameter
6"/8"
ELECTRIC (VOLTS)
120 V/60 Hz
AMPERAGE
NA
HERTZ
NA
WATTS
NA
LIGHTING
NA
BULB TYPE
NA
BULB INCLUDED
NA
NUMBER OF LIGHTS
NA
BULB WATTS
NA
GREASE FILTER TYPE
NA
DISHWASHERSAFE FILTER
NA
FILTER MATERIAL
NA
BLOWER TYPE
Needs Pairing with Arezzo Insert
CONTROL TYPE
Fully Retractable Rotating Knobs w/ Blue Backlighting
SPEED CONTROL
YES
NUMBER OF SPEEDS
4.00
REMOTE CONTROL
NO
POWER SOURCE
NA
OUTDOOR USE
NO
SMUDGE RESISTANT
NO
RECIRCULATION KIT NEEDED
NO
CFM REDUCTION
NA
DIMENSIONS
91 x 61 x 79
DIMENSIONSinches
ADJUSTABLE HEIGHT
NO
Minimum Overall Height - Top to Bottom
30"
Maximum Overall Height - Top to Bottom
30"
Overall Height - Top to Bottom
30"
Overall Width - Side to Side2
36"
Overall Depth - Front to Back
24"
Hood Height
30"
Minimum Compatible Ceiling Height
NA
Maximum Compatible Ceiling Height
NA
Minimum Height Above Cooktop (ELECTRIC)
= 24
Minimum Height Above Cooktop (GAS)
= 30
Maximum Height Above Cooktop
36"
Chimney Width - Side to Side
22 7/10"
Chimney Depth - Front to Back
17 7/32"
Chimney Height - Top to Bottom
24 5/8
RECIRCULATION KIT NUMBER
NA
CHIMNEY EXTENSION NUMBER
KIT0182781/KIT0182782
TELESCOPIC DUCT COVER
-
DUCT TRANSITION
-
TRANSITION REDUCER KIT
-
BACKDRAFT DAMPER
-
NON RETURN VALVE
-
UPGRADE FILTER
-
CFM REDUCTION KIT
-
BACKSPLASH KIT
-
INTERNAL BLOWER
-
INLINE BLOWER
-
EXTERNAL BLOWER
-
INLINE BLOWER SHELL KIT
-
EXTERNAL BLOWER SHELL KIT
-
HEAT LAMPS
-
SPACER/LINER
-
WALL MOUNT BRACKET
-
HIGH CEILING EXTENSION KIT
-
REMOTE CONTROL KIT
-
cUL listed
YES
UL listed
YES
AHAM verified
YES
TITLE 24
YES
Prop65Disclosure
YES
ENERGY STAR
NO
WIFI CAPABLE
NO
COMERCIAL USE APPROVED
NO
ADA COMPLIANT
NO
APP CAPABLE
NO
VENTILATION DIRECTION
HORIZONTAL
SMART COMPATIBLE
NO
FITLER INDICATOR LIGHT
NO
HEAT SENSOR
YES
CHAROCAL FILTER
NO
CERTIFICADO NOM
NA
DIMENSIONS inches
36" x 24" x 30"
Prop65 Disclosure
YES
GTIN
00190603004847
EAN
0190603004847
UPC
190603004847
Hush system
Heat guard
Grease collectors
Seamless look Professional performance
Elica easy mounting
Rear outlet installation
