PRODUCT DESCRIPTION
Specifications
Finishes
Black Glass + Cast Iron
Voltage
220 - 240 V
Bridge Zone
2
Controls
Touch control
Booster airflow
400 CFM
AMPERAGE
208V - 7.1 kW at 35,7 Amps
Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
SHIPPING WEIGHT (kg)
42.20
NET WEIGHT (kg)
31.50
CARTON LENGHT (mm)
1000.00
CARTON HEIGHT (mm)
546.00
CARTON DEPTH (mm)
609.00
VOLUMEN (M3)
0.33
SHIPPING WEIGHT
93.03
NET WEIGHT
69.45
CARTON LENGHT
39.37
CARTON HEIGHT
21.50
CARTON DEPTH
23.98
COUNTRY OF MANUFACTURE
PL
Finish
Black Ceramic Glass
Color
Deep-black
FEATURES
Timer,Easy to mantain,Stop and go,Delay switch off,_x001E_Temperature manager,Bridge zones,Total integration,Airmatic,Pot self-detection,Touch controls, Child lock, Long life filter ++
WIDTH (IN)
36"
WIDTH (CM)
90.00
AIRFLOW (M3/H)
680.00
CFM (MAX)
400.00
db (min)
NA
db (max)
33.85
SONES
0.4 - 5.0
GREASE FILTER TYPE
YES
DISHWASHERSAFE FILTER
YES
FILTER MATERIAL
Aluminum
BLOWER TYPE
Interior Unit
EXHAUST SIZE
Rectangular 10 x 3 1/4"
CONTROL TYPE
Electronic Glass Touch & Slide w/ Red Illumination
SPEED CONTROL
YES
NUMBER OF SPEEDS
4.00
REMOTE CONTROL
NO
POWER SOURCE
Hardwired
CFM REDUCTION
NO
HEATING LEVEL
9 levels + Boost
COOKING ZONE
4.00
Burner Style
Induction
Cooktop Type
Cooktop
Fuel Type
Induction
Element Type
Induction
Ignition Type
Electric
Induction
Yes
Number Of Burners
4.00
Hot Surface Indicator Lights
YES
Installation Type
Self Rimming or Flush Installation
Material
Ceramic Tempered Glass
Cooktop Surface Style
Glass-Top
Total BTUs
NA
Auto Shut Off
Yes
Child Lock
Yes
Approved for Commercial Use
No
Commercial
No
Continuous Grates
YES
Downdraft Ventilated
Yes
Griddle
No
Grill
No
Outdoor Approved
No
Power Burner
No
Sabbath Mode
No
Smart Home
No
WIFI APPROVED
No
Fingerprint Resistant Finish
No
Bridge Element
Yes
Pan Recognition Sensor
Yes
Warm Function
Yes
App Compatibility
NO
Wireless Communication
NO
ELECTRIC (VOLTS)
220 V/60 Hz
AMPERAGE
34.10
HERTZ
60 Hz
EXHAUST VERSION
Convertible with Kit
DIMENSIONS
90 x 51 x 21
DIMENSIONSinches
36" x 20 1/4" x 8 1/4"
Depth
20 1/4"
Height
8 1/4"
Width
36"
Cutout Depth
19 3/8"
Cutout Height
8 1/4"
Cutout Width
31 3/4"
Wattage
7.10
Back Left Burner Watts
3700.00
Back Middle Burner Watts
NA
Back Right Burner Watts
3700.00
Front Left Burner Watts
3700.00
Front Middle Burner Watts
NA
Front Right Burner Watts
3700.00
Middle Burner Watts
NA
Transition Conversion Fitting
FLN0188192A
Recirculating Kits
NA
Certifications
ADA, UL, cUL.
ADA
YES
CEC Approved for CA Sale
YES
Title 20 Compliant
YES
Energy Star
NO
Certification NOM
Activo
GTIN
00190603004137
EAN
0190603004137
UPC
190603004137
Timer
Easy to mantain
Stop and go
Delay switch off
_x001E_Temperature manager
Bridge zones
Total integration
Airmatic
Pot self-detection
Touch controls
Child lock
Long life filter ++
