PRODUCT DESCRIPTION
Specifications
Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
FREIGHT
8516609901.00
SHIPPING WEIGHT (kg)
41.90
NET WEIGHT (kg)
33.60
CARTON LENGHT (mm)
1014.00
CARTON HEIGHT (mm)
350.00
CARTON DEPTH (mm)
678.00
VOLUMEN (M3)
0.24
SHIPPING WEIGHT (Lb s)
92.37
NET WEIGHT
74.08
CARTON LENGHT (Inches)
39.92
CARTON HEIGHT
13.78
CARTON DEPTH
26.69
COUNTRY OF MANUFACTURE
MX
Finish
Black Ceramic Glass
Color
black
FEATURES
Timer, Easy to mantain, Stop and go, Delay switch off,_x001E_ Temperature manager, Bridge zones, Total integration, Airmatic, CFM reduction system, Pot self-detection, Touch controls , Child lock , Long life filter ++
WIDTH (IN)
36"
WIDTH (CM)
90.00
AIRFLOW (M3/H)
1020.00
CFM (MAX)
600.00
db (min)
NA
db (max)
36.40
SONES
1.8 - 6.8
GREASE FILTER TYPE
YES
DISHWASHERSAFE FILTER
YES
FILTER MATERIAL
Aluminum
BLOWER TYPE
Interior Unit
EXHAUST SIZE
Rectangular 10 x 3 1/4" or round 6" (Included)
CONTROL TYPE
Electronic Glass Touch & Slide w/ Red Illumination
SPEED CONTROL
YES
NUMBER OF SPEEDS
4.00
REMOTE CONTROL
NO
POWER SOURCE
Hardwired
CFM REDUCTION
YES
HEATING LEVEL
9 levels + Boost
COOKING ZONE
4.00
Burner Style
Induction
Cooktop Type
Downdraft Cooktop
Fuel Type
Induction
Element Type
Induction
Ignition Type
Automatic Electronic
Induction
Yes
Number Of Burners
4.00
Hot Surface Indicator Lights
YES
Installation Type
Self Rimming or Flush Installation
Material
Ceramic Tempered Glass
Cooktop Surface Style
Glass-Top
Total BTUs
NA
Auto Shut Off
Yes
Child Lock
Yes
Approved for Commercial Use
No
Commercial
No
Continuous Grates
YES
Downdraft Ventilated
Yes
Griddle
No
Grill
No
Ignition Type3
Electric
Outdoor Approved
No
Power Burner
No
Sabbath Mode
No
Smart Home
No
WIFI APPROVED
No
Fingerprint Resistant Finish
No
Bridge Element
Yes
Pan Recognition Sensor
Yes
Warm Function
Yes
App Compatibility
NO
Wireless Communication
NO
ELECTRIC (VOLTS)
220 V/60 Hz
AMPERAGE
32.00
HERTZ
62 Hz
EXHAUST VERSION
Convertible with Kit
DIMENSIONS
90 x 57 x 26
DIMENSIONS inches
36 1/16" x 22 9/16" x 10 3/16"
Depth
22 9/16"
Height
10 3/16"
Width
36 1/16"
Cutout Depth
21 1/8"
Cutout Height
10 3/16"
Cutout Width
34 9/16"
Wattage
7.70
Back Left Burner Watts
3700.00
Back Middle Burner Watts
NA
Back Right Burner Watts
3700.00
Front Left Burner Watts
3700.00
Front Middle Burner Watts
NA
Front Right Burner Watts
3700.00
Middle Burner Watts
NA
Transition Conversion Fitting
NA
Recirculating Kits
KIT0192765
Certifications
ADA, UL, cUL.
ADA
YES
CEC Approved for CA Sale
YES
Title 20 Compliant
YES
Energy Star
NO
Certificado NOM
Activo
CA Prop 65 Warning?
Yes
What Chemical Requires the Prop 65 Warning
NA
Uniform Packaging and Labeling Regulations (UPLR) Compliant
Na
Energy Efficiency Regulations Compliant
No
Safety Listing(s)
No
GTIN
00190603005707
EAN
0190603005707
UPC
190603005707
