Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
Fracci n arancelaria
8414600100.00
SHIPPING WEIGHT (kg)
22.80
CARTON LENGHT (mm)
999.00
CARTON HEIGHT (mm)
618.00
SHIPPING WEIGHT (lb)
50.27
COUNTRY OF MANUFACTURE
MX
INTENDED APPROVED USE
Residential use
Finish
Stainless Steel + Black Glass
Type of Ventilation
Convertible
HOODS FEATURES
Led light, Dim light, Top performance, CFM reduction system, Touch controls, Hush system
EXHAUST VERSION
Convertible with Kit
EXHAUST SIZE
Rectangular 10 x3 1/4" or round 6" (sold separately)
DUCT SHAPE
Rectangular or round (sold separately)
EXHAUST LOCATION
Top or Rear
RECTANGULAR DUCTH HEIGHT
10"
RECTANGULAR DUCT WIDTH
3.25
LIGHTING
Premium Dimmable LED 2 x 2.1 ww 4000 KK
GREASE FILTER TYPE
Dishwasher-Safe, Stainless Steel Microhole Filter
DISHWASHERSAFE FILTER
YES
FILTER MATERIAL
Stainless Steel
BLOWER TYPE
Interior Unit
CONTROL TYPE
Multi-function Electronic with black glass touch display
NUMBER OF SPEEDS
3 + booster
RECIRCULATION KIT NEEDED
YES
DIMENSIONS (CM)
91 x 50 x 25
DIMENSIONS (INCH)
36" x 19 5/8" x 9 3/4"
Overall Height - Top to Bottom
9 3/4"
Overall Width - Side to Side2
36"
Overall Depth - Front to Back
19 5/8"
Min - Max Compatible Ceiling Height (Cover electronic cooking)
NA
Min - Max Compatible Ceiling Height ( Cover gas cooking)
NA
Minimum Height Above Cooktop (ELECTRIC)
24
Minimum Height Above Cooktop (GAS)
30
Maximum Height Above Cooktop
36"
Chimney Width - Side to Side
NA
Chimney Depth - Front to Back
NA
Chimney Height - Top to Bottom
NA
Long Life Recirculating Carbon Filter
NA
Recirculation (400 CFM) 2 round carbon filters
NA
Recirculation (400 CFM) Contains 6 deflector & 3 carbon filters
NA
Recirculation (600 CFM) Contains 6 deflector, 3 flat carbon filters & clips
NA
Recirculation (600 CFM) Contains 6 deflector & 2 carbon filters
NA
Recirculation (600 CFM) 2 round carbon filters
KIT02667
Recirculation (600 CFM) 4 round carbon filters
NA
Recirculation (600 CFM) 6 round carbon filters
NA
Recirculation (600 CFM) 6 round Deflector
NA
Recirculation (1200 CFM) 4 round deflector
NA
Recirculation (1200 CFM) 4 round carbon filters
NA
Recirculation (1200 CFM) (8 round deflector)
NA
Long Chimney Ext/Chimney extension
NA
Chimney extension Can reach 8 8 - 12 4 (ducted), 9 0 -12 8 (recirculating)
NA
Chimney extension Can reach 7 9 - 10 9 (ducted), 8 1 -11 1 (recirculating)
NA
Chimney extension Reaches ceiling heights 8 5 -12 1 (ducted), 9 1 -12 5 (recirculating)
NA
Chimney extension Reaches ceiling heights 7 5 -10 3 (ducted), 8 2 -10 11 (recirculating)
NA
Long Chimney Extension(6 )
NA
Long Chimney Extension(11 )
NA
Long Chimney Extension(12 )
NA
Long Chimney Extension(13 )
NA
Long Chimney Extension (6 with grates)
NA
TRANSITION REDUCER KIT 10 round down to 8 round - attaches to 10 round transition
-
RECIRCULATION DUCT COVERS
NA
RECIRCULATION DEFLECTOR
NA
INLINE BLOWER SHELL KIT (600 CFM)
-
INLINE BLOWER SHELL KIT (1200 CFM)
NA
EXTERNAL BLOWER SHELL KIT
-
HIGH CEILING EXTENSION KIT
-
Duct cover extension 6
NA
Duct cover extension 18
NA
COMERCIAL USE APPROVED
NO
VENTILATION DIRECTION
HORIZONTAL
FITLER INDICATOR LIGHT
NO
