Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
SHIPPING WEIGHT (kg)
34.00
CARTON LENGHT (mm)
1020.00
CARTON HEIGHT (mm)
806.00
SHIPPING WEIGHT (lb)
74.96
COUNTRY OF MANUFACTURE
MX
INTENDED APPROVED USE
Residential use
Type of Ventilation
Vented
HOODS FEATURES
Hush systemHeat guardGrease collectorsProfessional performanceSeamless look
EXHAUST VERSION
Convertible with Kit
EXHAUST LOCATION
Top Only
RECTANGULAR DUCTH HEIGHT
NA
RECTANGULAR DUCT WIDTH
NA
LIGHTING
Premium LED 2 x 7.5 ww 3000 KK
GREASE FILTER TYPE
Dishwasher-Safe, Professional Stainless Steel Angled Baffle Filter
DISHWASHERSAFE FILTER
YES
FILTER MATERIAL
Stainless Steel
BLOWER TYPE
Interior Unit
CONTROL TYPE
Fully Retractable Rotating Knobs w/ Blue Backlighting
RECIRCULATION KIT NEEDED
NO
DIMENSIONS (CM)
90 x 60 x 76
DIMENSIONS_x000D_ (INCH)
36" x 24 x 30"
Minimum Overall Height - Top to Bottom
30"
Maximum Overall Height - Top to Bottom
47 5/8"
Overall Height - Top to Bottom
30 -47 5/8
Overall Width - Side to Side2
36"
Overall Depth - Front to Back
24
Min - Max Compatible Ceiling Height (Cover electronic cooking)
7'6"
Min - Max Compatible Ceiling Height ( Cover gas cooking)
10'0"
Minimum Height Above Cooktop (ELECTRIC)
= 24
Minimum Height Above Cooktop (GAS)
= 30
Maximum Height Above Cooktop
36"
Chimney Width - Side to Side
13 1/8"
Chimney Depth - Front to Back
10 3/4"
Chimney Height - Top to Bottom
35 7/16
RECIRCULATION KIT NUMBER
KIT0192765 + KIT0192759 + KIT01936
CHIMNEY EXTENTION NUMBER
KIT02785/KIT01935
CFM REDUCTION KIT
KIT0185752
EXTERNAL BLOWER
KIT0153054
INLINE BLOWER SHELL KIT
KIT0205342
EXTERNAL BLOWER SHELL KIT
-
HIGH CEILING EXTENSION KIT
-
Prop65_x000D_ Disclosure
YES
COMERCIAL USE APPROVED
NO
VENTILATION DIRECTION
HORIZONTAL
FITLER INDICATOR LIGHT
NO
