PRODUCT DESCRIPTION
Specifications
Width
30 , 36 , 42 , 48
Sones
Min 7 Max 8.2
Extraction capacity
600 CFM / 1200 CFM
Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
SHIPPING WEIGHT (kg)
33.50
NET WEIGHT (kg)
27.50
CARTON LENGHT (mm)
867.50
CARTON HEIGHT (mm)
806.00
CARTON WIDTH (mm)
456.00
VOLUMEN (M3)
0.30
SHIPPING WEIGHT
73.85
NET WEIGHT
60.63
CARTON LENGHT
34.15
CARTON HEIGHT
31.73
CARTON WIDTH
17.95
COUNTRY OF MANUFACTURE
MX
QTY PACKAGE
1.00
INTENDED APPROVED USE
Residential use
Finish
Stainless Steel
Color
inox
Type of Ventilation
Vented
HOODS FEATURES
Hush system, Heat guard, Grease collectors, Professional performance, Seamless look
WIDTH (IN)
30"
WIDTH (CM)
76.00
AIRFLOW (M3/H)
1020.00
CFM (MAX)
600.00
db (min)
36.00
db (max)
56.00
SONES
1.7 - 7.0
EXHAUST VERSION
Convertible with Kit
EXHAUST SIZE
Round 6"
DUCT SHAPE
Round
EXHAUST LOCATION
Top Only
RECTANGULAR DUCTH HEIGHT
NA
RECTANGULAR DUCT WIDTH
NA
Round duct diameter
6"
ELECTRIC (VOLTS)
120 V/60 Hz
AMPERAGE
4,1 A
HERTZ
60.00
WATTS
463.00
LIGHTING
Premium LED 2 x 7.5 ww 3000 KK
BULB TYPE
LED
BULB INCLUDED
YES
NUMBER OF LIGHTS
2.00
BULB WATTS
6.50
KELVINS
3000.00
GREASE FILTER TYPE
Dishwasher-Safe, Professional Stainless Steel Angled Baffle Filter
DISHWASHERSAFE FILTER
YES
FILTER MATERIAL
Stainless Steel
BLOWER TYPE
Interior Unit
CONTROL TYPE
Fully Retractable Rotating Knobs w/ Blue Backlighting
SPEED CONTROL
YES
NUMBER OF SPEEDS
4.00
REMOTE CONTROL
NO
POWER SOURCE
Hardwired
OUTDOOR USE
NO
SMUDGE RESISTANT
NO
RECIRCULATION KIT NEEDED
NO
CFM REDUCTION
Yes w/kit
DIMENSIONS
76 x 60 x 76
DIMENSIONSinches
ADJUSTABLE HEIGHT
YES
Minimum Overall Height - Top to Bottom
30"
Maximum Overall Height - Top to Bottom
47 5/8"
Overall Height - Top to Bottom
30 -47 5/8
Overall Width - Side to Side2
30"
Overall Depth - Front to Back
24
Hood Height
12 1/8"
Minimum Compatible Ceiling Height
7'6"
Maximum Compatible Ceiling Height
10'0"
Minimum Height Above Cooktop (ELECTRIC)
= 24
Minimum Height Above Cooktop (GAS)
= 30
Maximum Height Above Cooktop
36"
Chimney Width - Side to Side
13 1/8"
Chimney Depth - Front to Back
10 3/4"
Chimney Height - Top to Bottom
35 7/16
RECIRCULATION KIT NUMBER
KIT0192765 + KIT0192759 + KIT01936
CHIMNEY EXTENSION NUMBER
KIT02785/KIT01935
TELESCOPIC DUCT COVER
-
DUCT TRANSITION
-
TRANSITION REDUCER KIT
-
BACKDRAFT DAMPER
-
NON RETURN VALVE
-
UPGRADE FILTER
-
CFM REDUCTION KIT
KIT0185752
BACKSPLASH KIT
-
INTERNAL BLOWER
-
INLINE BLOWER
KIT0154387
EXTERNAL BLOWER
KIT0153054
INLINE BLOWER SHELL KIT
KIT0205342
EXTERNAL BLOWER SHELL KIT
-
HEAT LAMPS
-
SPACER/LINER
-
WALL MOUNT BRACKET
-
HIGH CEILING EXTENSION KIT
-
REMOTE CONTROL KIT
-
cUL listed
YES
UL listed
YES
AHAM verified
YES
TITLE 24
YES
Prop65Disclosure
YES
ENERGY STAR
NO
WIFI CAPABLE
NO
COMERCIAL USE APPROVED
NO
ADA COMPLIANT
NO
APP CAPABLE
NO
VENTILATION DIRECTION
HORIZONTAL
SMART COMPATIBLE
NO
FITLER INDICATOR LIGHT
NO
HEAT SENSOR
YES
CHAROCAL FILTER
NO
CERTIFICADO NOM
NA
DIMENSIONS inches
30" x 24 x 30"
Prop65 Disclosure
YES
GTIN
00190603002010
EAN
0190603002010
UPC
190603002010
Hush system
Heat guard
Grease collectors
Professional performance
Seamless look
