Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
SHIPPING WEIGHT (kg)
16.40
CARTON LENGHT (mm)
600.00
CARTON HEIGHT (mm)
600.00
SHIPPING WEIGHT (lb)
36.16
COUNTRY OF MANUFACTURE
IT
INTENDED APPROVED USE
Residential use
Finish
Stainless Steel White
Type of Ventilation
Non-Vented
HOODS FEATURES
Long Life Filter, Perimeter aspiration, Maintenance alarm, Led Light
EXHAUST VERSION
Recirculating Only
RECTANGULAR DUCTH HEIGHT
NA
RECTANGULAR DUCT WIDTH
NA
LIGHTING
LED 3 x 2.5 W 4000 K
GREASE FILTER TYPE
Dishwasher-Safe, Anodized Aluminum Mesh Filter + Perimeter Aspiration
DISHWASHERSAFE FILTER
YES
FILTER MATERIAL
Aluminum Mesh
BLOWER TYPE
Interior Unit
CONTROL TYPE
Electronic Push Buttons with Perimetral Light
NUMBER OF SPEEDS
3 + booster
RECIRCULATION KIT NEEDED
NO
DIMENSIONS (CM)
50.8 W x 50.8 D x 39.37 H
DIMENSIONS_x000D_ (INCH)
20 W x 20 D x 15 1/2"H
Minimum Overall Height - Top to Bottom
21 1/4"
Maximum Overall Height - Top to Bottom
51 3/16
Overall Height - Top to Bottom
21 1/4 -51 3/16
Overall Width - Side to Side2
20 1/4
Overall Depth - Front to Back
20 1/4
Min - Max Compatible Ceiling Height (Cover electronic cooking)
6'10"
Min - Max Compatible Ceiling Height ( Cover gas cooking)
11'8
Minimum Height Above Cooktop (ELECTRIC)
= 24
Minimum Height Above Cooktop (GAS)
= 30
Maximum Height Above Cooktop
36"
Chimney Width - Side to Side
NA
Chimney Depth - Front to Back
NA
Chimney Height - Top to Bottom
NA
RECIRCULATION KIT NUMBER
NA
CHIMNEY EXTENTION NUMBER
NA
INLINE BLOWER SHELL KIT
-
EXTERNAL BLOWER SHELL KIT
-
WALL MOUNT BRACKET
KIT0121394
HIGH CEILING EXTENSION KIT
KIT01921
Prop65_x000D_ Disclosure
YES
COMERCIAL USE APPROVED
NO
VENTILATION DIRECTION
HORIZONTAL
FITLER INDICATOR LIGHT
YES
