PRODUCT DESCRIPTION
Specifications
Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
SHIPPING WEIGHT (kg)
62.20
NET WEIGHT (kg)
51.20
CARTON LENGHT (mm)
880.00
CARTON HEIGHT (mm)
943.00
CARTON WIDTH (mm)
584.00
VOLUMEN (M3)
0.79
SHIPPING WEIGHT
137.13
NET WEIGHT
112.88
CARTON LENGHT
34.65
CARTON HEIGHT
37.13
CARTON WIDTH
22.99
COUNTRY OF MANUFACTURE
MX
QTY PACKAGE
1.00
INTENDED APPROVED USE
Residential use
Finish
Corrosion Resistant Grade Stainless Steel
Color
inox
Type of Ventilation
Non-Vented
HOODS FEATURES
Heat guard, Professional performance, Grease collectors, Seamless look
WIDTH (IN)
48"
WIDTH (CM)
120.00
AIRFLOW (M3/H)
2040.00
CFM (MAX)
1200.00
db (min)
35.65
db (max)
59.00
SONES
1.7 - 8.5
EXHAUST VERSION
Ducted Only
EXHAUST SIZE
Round 10"
DUCT SHAPE
Round
EXHAUST LOCATION
Top or Rear
RECTANGULAR DUCTH HEIGHT
NA
RECTANGULAR DUCT WIDTH
NA
Round duct diameter
10"
ELECTRIC (VOLTS)
120.00
AMPERAGE
7,6 A
HERTZ
60.00
WATTS
NA
LIGHTING
LED 4 x 6.5 ww 3000 KK
BULB TYPE
LED
BULB INCLUDED
YES
NUMBER OF LIGHTS
4.00
BULB WATTS
7.50
KELVINS
3000.00
GREASE FILTER TYPE
Dishwasher-Safe, Professional Stainless Steel Angled Baffle Filter
DISHWASHERSAFE FILTER
YES
FILTER MATERIAL
Stainless Steel
BLOWER TYPE
Sold separately
CONTROL TYPE
Fully Retractable Rotating Knobs w/ Blue Backlighting
SPEED CONTROL
YES
NUMBER OF SPEEDS
4.00
REMOTE CONTROL
NO
POWER SOURCE
Hardwired
OUTDOOR USE
YES
SMUDGE RESISTANT
NO
RECIRCULATION KIT NEEDED
NO
CFM REDUCTION
No
DIMENSIONS
120 x 80 x 45
DIMENSIONSinches
ADJUSTABLE HEIGHT
NO
Minimum Overall Height - Top to Bottom
17 15/16"
Maximum Overall Height - Top to Bottom
22 /
Overall Height - Top to Bottom
17 15/16"
Overall Width - Side to Side2
48"
Overall Depth - Front to Back
32"
Hood Height
17 15/16"
Minimum Compatible Ceiling Height
NA
Maximum Compatible Ceiling Height
NA
Minimum Height Above Cooktop (ELECTRIC)
24
Minimum Height Above Cooktop (GAS)
30
Maximum Height Above Cooktop
36"
Chimney Width - Side to Side
48"
Chimney Depth - Front to Back
11 15/16"
Chimney Height - Top to Bottom
12 1/
RECIRCULATION KIT NUMBER
NA
CHIMNEY EXTENSION NUMBER
KIT0156649/KIT0156641
TELESCOPIC DUCT COVER
KIT0205343
DUCT TRANSITION
10 Round (Top or Rear)
TRANSITION REDUCER KIT
NA
BACKDRAFT DAMPER
NA
NON RETURN VALVE
NA
UPGRADE FILTER
NA
CFM REDUCTION KIT
NA
BACKSPLASH KIT
-
INTERNAL BLOWER
KIT0198968
INLINE BLOWER
KIT0154387
EXTERNAL BLOWER
KIT0153054
INLINE BLOWER SHELL KIT
NA
EXTERNAL BLOWER SHELL KIT
NA
HEAT LAMPS
NA
SPACER/LINER
KIT0199479
WALL MOUNT BRACKET
NA
HIGH CEILING EXTENSION KIT
NA
REMOTE CONTROL KIT
NA
cUL listed
YES
UL listed
YES
AHAM verified
YES
TITLE 24
YES
Prop65Disclosure
YES
ENERGY STAR
NO
WIFI CAPABLE
NO
COMERCIAL USE APPROVED
NO
ADA COMPLIANT
NO
APP CAPABLE
NO
VENTILATION DIRECTION
HORIZONTAL
SMART COMPATIBLE
NO
FITLER INDICATOR LIGHT
NO
HEAT SENSOR
YES
CHAROCAL FILTER
NO
VERSION ADVANCES
The rear outlet was implemented, lampara, conexi n electrica, fijaci n de spacers
CERTIFICADO NOM
NA
DIMENSIONS inches
48" x 32" x 18"
Prop65 Disclosure
YES
CHIMNEY EXTENTION NUMBER
NA
SHIPPING WEIGHT (lb)
137.13
NET WEIGHT (lb)
112.88
Material
Stainless Steel
PANEL READY
NO
DIMENSIONS (CM)
122 x 81 x 46
DIMENSIONS (INCH)
48" W x 32" D x 18" H
Min - Max Compatible Ceiling Height (Cover electronic cooking)
NA
Min - Max Compatible Ceiling Height ( Cover gas cooking)
NA
LONG CHIMNEY EXTENSION NUMBER
NA
LONG CHIMNEY EXTENSION ( W/ GRATES)
NA
RECIRCULATION DUCT COVERS
NA
RECIRCULATION DEFLECTOR
NA
RECIRCULATION FILTERS
NA
BACKSPLASS KIT
NA
DUCT COVER
KIT0156641 / KIT0156649
ETL
YES
Heat guard
Professional performance
Grease collectors
Seamless look
