PRODUCT DESCRIPTION
Specifications
Width
36 , 48
Sones
Min 8.2 Max 8.7
Extraction capacity
1200 CFM
Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
SHIPPING WEIGHT (kg)
50.40
NET WEIGHT (kg)
40.40
CARTON LENGHT (mm)
1044.00
CARTON HEIGHT (mm)
943.00
CARTON WIDTH (mm)
584.00
VOLUMEN (M3)
0.41
SHIPPING WEIGHT
111.11
NET WEIGHT
89.07
CARTON LENGHT
41.10
CARTON HEIGHT
37.13
CARTON WIDTH
22.99
COUNTRY OF MANUFACTURE
MX
QTY PACKAGE
1.00
INTENDED APPROVED USE
Residential use
Finish
Corrosion Resistant Grade Stainless Steel
Color
inox
Type of Ventilation
Non-Vented
HOODS FEATURES
Heat guard, Professional performance, Grease collectors, Seamless look
WIDTH (IN)
36"
WIDTH (CM)
90.00
AIRFLOW (M3/H)
2040.00
CFM (MAX)
1200.00
db (min)
35.65
db (max)
59.00
SONES
1.7 - 8.5
EXHAUST VERSION
Ducted Only
EXHAUST SIZE
Round 10"
DUCT SHAPE
Round
EXHAUST LOCATION
Top or Rear
RECTANGULAR DUCTH HEIGHT
NA
RECTANGULAR DUCT WIDTH
NA
Round duct diameter
10"
ELECTRIC (VOLTS)
120 V/60 Hz
AMPERAGE
7,7 A
HERTZ
60.00
WATTS
NA
LIGHTING
LED 2 x 6.5 ww 3000 KK
BULB TYPE
LED
BULB INCLUDED
YES
NUMBER OF LIGHTS
2.00
BULB WATTS
7.50
KELVINS
3000.00
GREASE FILTER TYPE
Dishwasher-Safe, Professional Stainless Steel Angled Baffle Filter
DISHWASHERSAFE FILTER
YES
FILTER MATERIAL
Stainless Steel
BLOWER TYPE
Sold separately
CONTROL TYPE
Fully Retractable Rotating Knobs w/ Blue Backlighting
SPEED CONTROL
YES
NUMBER OF SPEEDS
4.00
REMOTE CONTROL
NO
POWER SOURCE
Hardwired
OUTDOOR USE
YES
SMUDGE RESISTANT
NO
RECIRCULATION KIT NEEDED
NO
CFM REDUCTION
No
DIMENSIONS
91 x 80 x 45
DIMENSIONS inches
36" x 32" x 18"
ADJUSTABLE HEIGHT
NO
Minimum Overall Height - Top to Bottom
18"
Maximum Overall Height - Top to Bottom
18"
Overall Height - Top to Bottom
18"
Overall Width - Side to Side2
36"
Overall Depth - Front to Back
32"
Hood Height
18"
Minimum Compatible Ceiling Height
NA
Maximum Compatible Ceiling Height
NA
Minimum Height Above Cooktop
30"
Maximum Height Above Cooktop
36"
Chimney Width - Side to Side
36"
Chimney Depth - Front to Back
11 15/16"
Chimney Height - Top to Bottom
6"/12"
STYLE
Modern
RECIRCULATION KIT NUMBER
NA
CHIMNEY EXTENSION NUMBER
KIT0156645/KIT0156637
TELESCOPIC DUCT COVER
KIT0205343
DUCT TRANSITION
-
TRANSITION REDUCER KIT
-
BACKDRAFT DAMPER
-
NON RETURN VALVE
-
UPGRADE FILTER
-
CFM REDUCTION KIT
-
BACKSPLASH KIT
-
INTERNAL BLOWER
KIT0156655
INLINE BLOWER
KIT0154387
EXTERNAL BLOWER
KIT0153054
INLINE BLOWER SHELL KIT
-
EXTERNAL BLOWER SHELL KIT
-
HEAT LAMPS
-
SPACER/LINER
KIT0153304
WALL MOUNT BRACKET
-
HIGH CEILING EXTENSION KIT
-
REMOTE CONTROL KIT
-
cUL listed
YES
UL listed
YES
AHAM verified
YES
TITLE 24
YES
Prop65 Disclosure
YES
ENERGY STAR
NO
WIFI CAPABLE
NO
COMERCIAL USE APPROVED
NO
ADA COMPLIANT
NO
APP CAPABLE
NO
VENTILATION DIRECTION
HORIZONTAL
SMART COMPATIBLE
NO
FITLER INDICATOR LIGHT
NO
HEAT SENSOR
YES
CHAROCAL FILTER
NO
VERSION ADVANCES
The rear outlet was implemented
CERTIFICADO NOM
No
GTIN
00190603002300
EAN
0190603002300
UPC
190603002300
Heat guard
Professional performance
Grease collectors
Seamless look
