Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
Fracci n arancelaria
8414901099.00
SHIPPING WEIGHT (kg)
50.40
CARTON LENGHT (mm)
1044.00
CARTON HEIGHT (mm)
943.00
SHIPPING WEIGHT (lb)
111.11
COUNTRY OF MANUFACTURE
MX
INTENDED APPROVED USE
Residential use
Finish
Corrosion Resistant Grade Stainless Steel
Type of Ventilation
Non-Vented
HOODS FEATURES
Heat guard, Professional performance, Grease collectors, Seamless look
EXHAUST VERSION
Ducted Only
EXHAUST LOCATION
Top or Rear
RECTANGULAR DUCTH HEIGHT
NA
RECTANGULAR DUCT WIDTH
NA
LIGHTING
LED 2 x 6.5 ww 3000 KK
GREASE FILTER TYPE
Dishwasher-Safe, Professional Stainless Steel Angled Baffle Filter
DISHWASHERSAFE FILTER
YES
FILTER MATERIAL
Stainless Steel
BLOWER TYPE
Sold separately
CONTROL TYPE
Fully Retractable Rotating Knobs w/ Blue Backlighting
RECIRCULATION KIT NEEDED
NO
DIMENSIONS (CM)
91 x 81 x 46
DIMENSIONS (INCH)
36" W x 32" D x 18" H
Overall Height - Top to Bottom
17 15/16"
Overall Width - Side to Side2
36"
Overall Depth - Front to Back
32"
Min - Max Compatible Ceiling Height (Cover electronic cooking)
NA
Min - Max Compatible Ceiling Height ( Cover gas cooking)
NA
Minimum Height Above Cooktop (ELECTRIC)
24
Minimum Height Above Cooktop (GAS)
30
Maximum Height Above Cooktop
36"
Chimney Width - Side to Side
36"
Chimney Depth - Front to Back
11 15/16"
Chimney Height - Top to Bottom
12 1/
Long Life Recirculating Carbon Filter
NA
Recirculation (400 CFM) 2 round carbon filters
NA
Recirculation (400 CFM) Contains 6 deflector & 3 carbon filters
NA
Recirculation (600 CFM) Contains 6 deflector, 3 flat carbon filters & clips
NA
Recirculation (600 CFM) Contains 6 deflector & 2 carbon filters
NA
Recirculation (600 CFM) 2 round carbon filters
NA
Recirculation (600 CFM) 4 round carbon filters
NA
Recirculation (600 CFM) 6 round carbon filters
NA
Recirculation (600 CFM) 6 round Deflector
NA
Recirculation (1200 CFM) 4 round deflector
NA
Recirculation (1200 CFM) 4 round carbon filters
NA
Recirculation (1200 CFM) (8 round deflector)
NA
Long Chimney Ext/Chimney extension
NA
Chimney extension Can reach 8 8 - 12 4 (ducted), 9 0 -12 8 (recirculating)
NA
Chimney extension Can reach 7 9 - 10 9 (ducted), 8 1 -11 1 (recirculating)
NA
Chimney extension Reaches ceiling heights 8 5 -12 1 (ducted), 9 1 -12 5 (recirculating)
NA
Chimney extension Reaches ceiling heights 7 5 -10 3 (ducted), 8 2 -10 11 (recirculating)
NA
Long Chimney Extension(6 )
NA
Long Chimney Extension(11 )
NA
Long Chimney Extension(12 )
NA
Long Chimney Extension(13 )
NA
Long Chimney Extension (6 with grates)
NA
TELESCOPIC DUCT COVER
KIT0205343
DUCT TRANSITION
10 Round (Top or Rear)
TRANSITION REDUCER KIT 10 round down to 8 round - attaches to 10 round transition
NA
RECIRCULATION DUCT COVERS
NA
RECIRCULATION DEFLECTOR
NA
INTERNAL BLOWER
KIT0198968
EXTERNAL BLOWER
KIT0153054
INLINE BLOWER SHELL KIT (600 CFM)
NA
INLINE BLOWER SHELL KIT (1200 CFM)
NA
EXTERNAL BLOWER SHELL KIT
NA
HIGH CEILING EXTENSION KIT
NA
Duct cover extension 6
KIT0156637 / KIT0156645
Duct cover extension 18
NA
COMERCIAL USE APPROVED
NO
VENTILATION DIRECTION
HORIZONTAL
FITLER INDICATOR LIGHT
NO
VERSION ADVANCES
The rear outlet was implemented, lampara, conexi n electrica, fijaci n de spacers
