PRODUCT DESCRIPTION
Specifications
Width
36 , 42
Sones
7
Extraction capacity
600 CFM
Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
SHIPPING WEIGHT (kg)
43.10
NET WEIGHT (kg)
31.30
CARTON LENGHT (mm)
1195.00
CARTON HEIGHT (mm)
596.00
CARTON WIDTH (mm)
850.00
VOLUMEN (M3)
0.60
SHIPPING WEIGHT
95.02
NET WEIGHT
69.00
CARTON LENGHT
47.05
CARTON HEIGHT
23.46
CARTON WIDTH
33.46
COUNTRY OF MANUFACTURE
MX
QTY PACKAGE
1.00
INTENDED APPROVED USE
Residential use
Finish
Stainless Steel + Black Glass
Color
inox + glass
Type of Ventilation
Convertible
HOODS FEATURES
Hush system, Dim light, Top performance, CFM reduction system, Touch controls , Led light
WIDTH (IN)
36"
WIDTH (CM)
90.00
AIRFLOW (M3/H)
0.00
CFM (MAX)
600.00
db (min)
36.00
db (max)
55.00
SONES
1.7 - 6.8
EXHAUST VERSION
Convertible with Kit
EXHAUST SIZE
Round 6"
DUCT SHAPE
Round
EXHAUST LOCATION
Top Only
RECTANGULAR DUCTH HEIGHT
NA
RECTANGULAR DUCT WIDTH
NA
Round duct diameter
6"
ELECTRIC (VOLTS)
120 V/60 Hz
AMPERAGE
3.8 A
HERTZ
60.00
WATTS
394.00
LIGHTING
Premium Dimmable LED 2 x 2.1 ww 4000 KK
BULB TYPE
LED
BULB INCLUDED
YES
NUMBER OF LIGHTS
2.00
BULB WATTS
2.10
KELVINS
4000.00
GREASE FILTER TYPE
Dishwasher-Safe, Stainless Steel Microhole Filter
DISHWASHERSAFE FILTER
YES
FILTER MATERIAL
Stainless Steel
BLOWER TYPE
Interior Unit
CONTROL TYPE
Multi-function Electronic with black glass touch display
SPEED CONTROL
YES
NUMBER OF SPEEDS
4.00
REMOTE CONTROL
NO
POWER SOURCE
Hardwired
OUTDOOR USE
NO
SMUDGE RESISTANT
NO
RECIRCULATION KIT NEEDED
YES
CFM REDUCTION
Yes
DIMENSIONS
107 x 64 x 74
DIMENSIONSinches
ADJUSTABLE HEIGHT
YES
Minimum Overall Height - Top to Bottom
29 3/4"
Maximum Overall Height - Top to Bottom
49 1/2"
Overall Height - Top to Bottom
29 3/4"-49 1/2"
Overall Width - Side to Side2
42"
Overall Depth - Front to Back
25 1/4"
Hood Height
1 15/16"
Minimum Compatible Ceiling Height
7'6"
Maximum Compatible Ceiling Height
10'1"
Minimum Height Above Cooktop (ELECTRIC)
= 24
Minimum Height Above Cooktop (GAS)
= 30
Maximum Height Above Cooktop
36"
Chimney Width - Side to Side
13"
Chimney Depth - Front to Back
12"
Chimney Height - Top to Bottom
29 13/32
RECIRCULATION KIT NUMBER
KIT02665
CHIMNEY EXTENSION NUMBER
KIT0100317
TELESCOPIC DUCT COVER
-
DUCT TRANSITION
-
TRANSITION REDUCER KIT
-
BACKDRAFT DAMPER
-
NON RETURN VALVE
-
UPGRADE FILTER
-
CFM REDUCTION KIT
-
BACKSPLASH KIT
-
INTERNAL BLOWER
-
INLINE BLOWER
-
EXTERNAL BLOWER
-
INLINE BLOWER SHELL KIT
-
EXTERNAL BLOWER SHELL KIT
-
HEAT LAMPS
-
SPACER/LINER
-
WALL MOUNT BRACKET
-
HIGH CEILING EXTENSION KIT
-
REMOTE CONTROL KIT
-
cUL listed
YES
UL listed
YES
AHAM verified
YES
TITLE 24
YES
Prop65Disclosure
YES
ENERGY STAR
NO
WIFI CAPABLE
NO
COMERCIAL USE APPROVED
NO
ADA COMPLIANT
NO
APP CAPABLE
NO
VENTILATION DIRECTION
HORIZONTAL
SMART COMPATIBLE
NO
FITLER INDICATOR LIGHT
NO
HEAT SENSOR
NO
CHAROCAL FILTER
YES
CERTIFICADO NOM
NA
DIMENSIONS inches
42" x 25 1/4" x 29 3/4"
Prop65 Disclosure
YES
GTIN
00190603001716
EAN
0190603001716
UPC
190603001716
Hush system
Dim light
Top performance
CFM reduction system
Touch controls
Led light
