Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
Fracci n arancelaria
8414809999.00
SHIPPING WEIGHT (kg)
41.30
CARTON LENGHT (mm)
1040.00
CARTON HEIGHT (mm)
596.00
SHIPPING WEIGHT (lb)
91.05
COUNTRY OF MANUFACTURE
MX
INTENDED APPROVED USE
Residential use
Finish
Stainless Steel + Black Glass
Type of Ventilation
Convertible
HOODS FEATURES
Hush system, Dim light, Top performance, CFM reduction system, Touch controls , Led light
EXHAUST VERSION
Convertible with Kit
EXHAUST LOCATION
Top Only
RECTANGULAR DUCTH HEIGHT
NA
RECTANGULAR DUCT WIDTH
NA
LIGHTING
Premium Dimmable LED 2 x 2.1 ww 4000 KK
GREASE FILTER TYPE
Dishwasher-Safe, Stainless Steel Microhole Filter
DISHWASHERSAFE FILTER
YES
FILTER MATERIAL
Stainless Steel
BLOWER TYPE
Interior Unit
CONTROL TYPE
Multi-function Electronic with black glass touch display
RECIRCULATION KIT NEEDED
YES
DIMENSIONS (CM)
91 x 64 x 74
DIMENSIONS (INCH)
36" x 25 1/4" x 29 3/4"
Overall Height - Top to Bottom
29 3/4"-49 1/2"
Overall Width - Side to Side2
36"
Overall Depth - Front to Back
25 1/4"
Min - Max Compatible Ceiling Height (Cover electronic cooking)
7'6"
Min - Max Compatible Ceiling Height ( Cover gas cooking)
10'1"
Minimum Height Above Cooktop (ELECTRIC)
24
Minimum Height Above Cooktop (GAS)
30
Maximum Height Above Cooktop
36"
Chimney Width - Side to Side
13"
Chimney Depth - Front to Back
12"
Chimney Height - Top to Bottom
29 13/32
RECIRCULATION KIT
KIT02665
Long Life Recirculating Carbon Filter
NA
Recirculation (400 CFM) 2 round carbon filters
NA
Recirculation (400 CFM) Contains 6 deflector & 3 carbon filters
NA
Recirculation (600 CFM) Contains 6 deflector, 3 flat carbon filters & clips
NA
Recirculation (600 CFM) Contains 6 deflector & 2 carbon filters
NA
Recirculation (600 CFM) 2 round carbon filters
NA
Recirculation (600 CFM) 4 round carbon filters
NA
Recirculation (600 CFM) 6 round carbon filters
NA
Recirculation (600 CFM) 6 round Deflector
NA
Recirculation (1200 CFM) 4 round deflector
NA
Recirculation (1200 CFM) 4 round carbon filters
NA
Recirculation (1200 CFM) (8 round deflector)
NA
Long Chimney Ext/Chimney extension
KIT0100317
Chimney extension Can reach 8 8 - 12 4 (ducted), 9 0 -12 8 (recirculating)
NA
Chimney extension Can reach 7 9 - 10 9 (ducted), 8 1 -11 1 (recirculating)
NA
Chimney extension Reaches ceiling heights 8 5 -12 1 (ducted), 9 1 -12 5 (recirculating)
NA
Chimney extension Reaches ceiling heights 7 5 -10 3 (ducted), 8 2 -10 11 (recirculating)
NA
Long Chimney Extension(6 )
NA
Long Chimney Extension(11 )
NA
Long Chimney Extension(12 )
NA
Long Chimney Extension(13 )
NA
Long Chimney Extension (6 with grates)
NA
TRANSITION REDUCER KIT 10 round down to 8 round - attaches to 10 round transition
-
RECIRCULATION DUCT COVERS
NA
RECIRCULATION DEFLECTOR
NA
INLINE BLOWER SHELL KIT (600 CFM)
-
INLINE BLOWER SHELL KIT (1200 CFM)
NA
EXTERNAL BLOWER SHELL KIT
-
HIGH CEILING EXTENSION KIT
-
Duct cover extension 6
NA
Duct cover extension 18
NA
COMERCIAL USE APPROVED
NO
VENTILATION DIRECTION
HORIZONTAL
FITLER INDICATOR LIGHT
NO
