Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
SHIPPING WEIGHT (kg)
45.40
CARTON LENGHT (mm)
1638.00
CARTON HEIGHT (mm)
821.80
SHIPPING WEIGHT (lb)
100.09
COUNTRY OF MANUFACTURE
MX
INTENDED APPROVED USE
Residential use
Finish
Stainless Steel + panel ready
Type of Ventilation
Convertible
HOODS FEATURES
Tune white,Long life filter,Dim light,Total integration,Super easy installation,Remote control,Perimeter aspiration,Panel ready,
AIRFLOW (M3/H)
1020 / 2040
EXHAUST VERSION
Convertible with Kit
EXHAUST SIZE
Round 6" Multidirectional
EXHAUST LOCATION
Multidirectional
RECTANGULAR DUCTH HEIGHT
NA
RECTANGULAR DUCT WIDTH
NA
LIGHTING
Dimmable Strip LED 3 x 14 W 3500 K
GREASE FILTER TYPE
Dishwasher-Safe, Anodized Aluminum Mesh Filter + Perimeter Aspiration
DISHWASHERSAFE FILTER
YES
FILTER MATERIAL
Aluminum Mesh
BLOWER TYPE
Sold separately
CONTROL TYPE
White remote control
POWER SOURCE
Junction Box
RECIRCULATION KIT NEEDED
YES
DIMENSIONS (CM)
152.4 W x 62.39 D x 30.64 H
DIMENSIONS_x000D_ (INCH)
60 W x 24 9/16 D x 12 /16 H
Minimum Overall Height - Top to Bottom
12 1/16"
Maximum Overall Height - Top to Bottom
12 1/16"
Overall Height - Top to Bottom
12 1/16"
Overall Width - Side to Side2
60"
Overall Depth - Front to Back
24 9/16"
Min - Max Compatible Ceiling Height (Cover electronic cooking)
NA
Min - Max Compatible Ceiling Height ( Cover gas cooking)
10'0"
Minimum Height Above Cooktop (ELECTRIC)
= 24
Minimum Height Above Cooktop (GAS)
= 30
Maximum Height Above Cooktop
NA
Chimney Width - Side to Side
NA
Chimney Depth - Front to Back
NA
Chimney Height - Top to Bottom
NA
RECIRCULATION KIT NUMBER
KIT0192765
CHIMNEY EXTENTION NUMBER
NA
CFM REDUCTION KIT
KIT0185099/KIT0185752
INTERNAL BLOWER
KIT0198146/KIT0198147
INLINE BLOWER
KIT0154387/KIT0198148
EXTERNAL BLOWER
KIT0153054
INLINE BLOWER SHELL KIT
-
EXTERNAL BLOWER SHELL KIT
-
HIGH CEILING EXTENSION KIT
-
REMOTE CONTROL KIT
KIT0121469/ KIT0121468
Prop65_x000D_ Disclosure
YES
COMERCIAL USE APPROVED
NO
VENTILATION DIRECTION
HORIZONTAL
FITLER INDICATOR LIGHT
YES
