Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
SHIPPING WEIGHT (kg)
32.80
CARTON LENGHT (mm)
1129.00
CARTON HEIGHT (mm)
385.00
SHIPPING WEIGHT (lb)
72.31
COUNTRY OF MANUFACTURE
MX
INTENDED APPROVED USE
Residential use
Finish
Stainless Steel + panel ready
Type of Ventilation
Convertible
HOODS FEATURES
Tune white,Long life filter,Dim light,Total integration,Super easy installation,Remote control,Perimeter aspiration,Panel ready,
AIRFLOW (M3/H)
1020 / 2040
EXHAUST VERSION
Convertible with Kit
EXHAUST SIZE
Round 6" Multidirectional
EXHAUST LOCATION
Multidirectional
RECTANGULAR DUCTH HEIGHT
NA
RECTANGULAR DUCT WIDTH
NA
LIGHTING
Dimmable Strip LED 2 x 14 W 3500 K
GREASE FILTER TYPE
Dishwasher-Safe, Anodized Aluminum Mesh Filter + Perimeter Aspiration
DISHWASHERSAFE FILTER
YES
FILTER MATERIAL
Aluminum Mesh
BLOWER TYPE
Sold separately
CONTROL TYPE
White remote control
POWER SOURCE
Junction Box
RECIRCULATION KIT NEEDED
YES
DIMENSIONS (CM)
102 x 50 x 31
DIMENSIONS_x000D_ (INCH)
40 x 19 7/8 x 12 1/16
Minimum Overall Height - Top to Bottom
12 1/16"
Maximum Overall Height - Top to Bottom
12 1/16"
Overall Height - Top to Bottom
12 1/16"
Overall Width - Side to Side2
40"
Overall Depth - Front to Back
19 7/8"
Min - Max Compatible Ceiling Height (Cover electronic cooking)
NA
Min - Max Compatible Ceiling Height ( Cover gas cooking)
10'0"
Minimum Height Above Cooktop (ELECTRIC)
= 24
Minimum Height Above Cooktop (GAS)
= 30
Maximum Height Above Cooktop
NA
Chimney Width - Side to Side
NA
Chimney Depth - Front to Back
NA
Chimney Height - Top to Bottom
NA
SEI (SUPER EASY INSTALLATION) America
8.00
LONG LIFE FILTER America
5.00
TOTAL INTEGRATION America
9.00
PERIMETER ASPIRATION America
5.00
RECIRCULATION KIT
KIT0192765
Long Life Recirculating Carbon Filter
NA
Recirculation (400 CFM) 2 round carbon filters
NA
Recirculation (400 CFM) Contains 6 deflector & 3 carbon filters
NA
Recirculation (600 CFM) Contains 6 deflector, 3 flat carbon filters & clips
NA
Recirculation (600 CFM) Contains 6 deflector & 2 carbon filters
NA
Recirculation (600 CFM) 2 round carbon filters
NA
Recirculation (600/1200 CFM) 4 round carbon filters
KIT0192765
Recirculation (600 CFM) 6 " round deflector
NA
Recirculation (600 CFM) 6 round Deflector
NA
Recirculation (1200 CFM) 4 round deflector
NA
Recirculation 4 round carbon filters
NA
Recirculation(8 round deflector)
NA
Long Chimney Ext/Chimney extension
NA
Chimney extension Can reach 8 8 - 12 4 (ducted), 9 0 -12 8 (recirculating)
NA
Chimney extension Can reach 7 9 - 10 9 (ducted), 8 1 -11 1 (recirculating)
NA
Chimney extension Reaches ceiling heights 8 5 -12 1 (ducted), 9 1 -12 5 (recirculating)
NA
Chimney extension Reaches ceiling heights 7 5 -10 3 (ducted), 8 2 -10 11 (recirculating)
NA
Long Chimney Extension(6 )
NA
Long Chimney Extension(11 )
NA
Long Chimney Extension(12 )
NA
Long Chimney Extension(13 )
NA
Long Chimney Extension_x000D_ (6 with grates)
NA
TRANSITION REDUCER KIT 10 round down to 8 round - attaches to 10 round transition
NA
RECIRCULATION DUCT COVERS
NA
RECIRCULATION DEFLECTOR
NA
CFM REDUCTION KIT
KIT0185099/KIT0185752
INTERNAL BLOWER
KIT0198146/KIT0198147
INLINE BLOWER (1200CFM)
KIT0154387/KIT0198148
EXTERNAL BLOWER (1200 CFM)
KIT0153054
INLINE BLOWER SHELL KIT (600 CFM)
NA
INLINE BLOWER SHELL KIT
NA
EXTERNAL BLOWER SHELL KIT
NA
HIGH CEILING EXTENSION KIT
NA
REMOTE CONTROL KIT
KIT0184524A/KIT0184525A
Duct cover extension 6
NA
Duct cover extension 18
NA
ELECTRONIC CFM REDUCTION BYPASS
NA
Prop65_x000D_ Disclosure
YES
COMERCIAL USE APPROVED
NO
VENTILATION DIRECTION
HORIZONTAL
FITLER INDICATOR LIGHT
YES
