PRODUCT DESCRIPTION
Specifications
Width
30 , 36
Sones
6
Extraction capacity
400 CFM
Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
SHIPPING WEIGHT (kg)
12.50
NET WEIGHT (kg)
10.00
CARTON LENGHT (mm)
864.00
CARTON HEIGHT (mm)
618.00
CARTON WIDTH (mm)
249.00
VOLUMEN (M3)
0.13
SHIPPING WEIGHT
27.56
NET WEIGHT
22.05
CARTON LENGHT
34.02
CARTON HEIGHT
24.33
CARTON WIDTH
9.80
COUNTRY OF MANUFACTURE
MX
QTY PACKAGE
1.00
INTENDED APPROVED USE
Residential use
Finish
Stainless Steel
Color
inox
Type of Ventilation
Convertible
HOODS FEATURES
3x layer mesh, Led light, CFM reduction system
WIDTH (IN)
30"
WIDTH (CM)
76.00
AIRFLOW (M3/H)
680.00
CFM (MAX)
400.00
db (min)
26.40
db (max)
51.00
SONES
0.9 - 5.0
EXHAUST VERSION
Convertible with Kit
EXHAUST SIZE
Rectangular 10 x 3 1/4" or round 7" (sold separately)
DUCT SHAPE
Rectangular or round (sold separately)
EXHAUST LOCATION
Top or Rear
RECTANGULAR DUCTH HEIGHT
10"
RECTANGULAR DUCT WIDTH
3.25
Round duct diameter
7"
ELECTRIC (VOLTS)
120 V/60 Hz
AMPERAGE
3A
HERTZ
60.00
WATTS
445.00
LIGHTING
LED 2 x 2.1 ww 3000 KK
BULB TYPE
LED
BULB INCLUDED
YES
NUMBER OF LIGHTS
2.00
BULB WATTS
6.50
KELVINS
3000.00
GREASE FILTER TYPE
Dishwasher-Safe, Anodized Aluminum Mesh Filter
DISHWASHERSAFE FILTER
YES
FILTER MATERIAL
Aluminum Mesh
BLOWER TYPE
Interior Unit
CONTROL TYPE
Electronic Touch Controls with Adjustable Color Backlight
SPEED CONTROL
YES
NUMBER OF SPEEDS
4.00
REMOTE CONTROL
NO
POWER SOURCE
Hardwired
OUTDOOR USE
NO
SMUDGE RESISTANT
NO
RECIRCULATION KIT NEEDED
YES
CFM REDUCTION
Yes
DIMENSIONS
76 x 51 x 12
DIMENSIONS inches
30" x 20" x 4 3/4"
ADJUSTABLE HEIGHT
NO
Minimum Overall Height - Top to Bottom
4 3/4"
Maximum Overall Height - Top to Bottom
4 3/4"
Overall Height - Top to Bottom
4 3/4"
Overall Width - Side to Side2
30"
Overall Depth - Front to Back
20"
Hood Height
4 3/4"
Minimum Compatible Ceiling Height
NA
Maximum Compatible Ceiling Height
NA
Minimum Height Above Cooktop
30"
Maximum Height Above Cooktop
36"
Chimney Width - Side to Side
NA
Chimney Depth - Front to Back
NA
Chimney Height - Top to Bottom
NA
STYLE
Modern
RECIRCULATION KIT NUMBER
KIT02178
CHIMNEY EXTENSION NUMBER
NA
TELESCOPIC DUCT COVER
-
DUCT TRANSITION
-
TRANSITION REDUCER KIT
-
BACKDRAFT DAMPER
KIT02723
NON RETURN VALVE
-
UPGRADE FILTER
GRI0131086A
CFM REDUCTION KIT
-
BACKSPLASH KIT
-
INTERNAL BLOWER
-
INLINE BLOWER
-
EXTERNAL BLOWER
-
INLINE BLOWER SHELL KIT
-
EXTERNAL BLOWER SHELL KIT
-
HEAT LAMPS
-
SPACER/LINER
-
WALL MOUNT BRACKET
-
HIGH CEILING EXTENSION KIT
-
REMOTE CONTROL KIT
-
cUL listed
YES
UL listed
YES
AHAM verified
YES
TITLE 24
YES
Prop65 Disclosure
YES
ENERGY STAR
NO
WIFI CAPABLE
NO
COMERCIAL USE APPROVED
NO
ADA COMPLIANT
NO
APP CAPABLE
NO
VENTILATION DIRECTION
HORIZONTAL
SMART COMPATIBLE
NO
FITLER INDICATOR LIGHT
NO
HEAT SENSOR
NO
CHAROCAL FILTER
YES
CERTIFICADO NOM
No
GTIN
00190603000153
EAN
0190603000153
UPC
190603000153
3x layer mesh
Led light
CFM reduction system
