PRODUCT DESCRIPTION
Features
Dishwasher-safe grates
(P) A special enameling process allows the grates to be washed directly in the dishwasher instead of by hand for easier clean up.(/P)
Sleek Knobs with LED Indicators
(P) Control knobs with an embedded red LED light line indicate if the burner is on or if there is residual heat.(/P)
Simmer delicate sauces with the OptiSim(R) Burner
(P) The OptiSim burner design is wider and thicker which diffuses heat evenly for better flame control when simmering delicate sauces.(/P)
Boil water quickly with a Dual-Flame Power Burner
(P) The dual flame ring power burner has two rings for low and high flame settings so you can go from simmer to sear with ease. Heat level 1-3 uses the inner ring, and 4-9 uses both rings for maximum heat.(/P)
Specifications
Energy source
Gas
Type of Control
Front, Illuminated, sword knobs
Safety
SMARTFLAME
Features
Flame select, Wok burner
Color of frame
Stainless steel
Color of Surface
Stainless steel
Design
Built-in
Number of electric elements
0
Number of electric cooking zones
0
Number of gas burners
5
Number of halogen elements
0
Installation Type
Built-in
Type of grate
Cast iron
Total Number of Heating Elements
5
Number of radiant elements
0
Number of electric warming zones
0
Overall Appliance Dimensions (HxWxD) (in)
3 13/16'' x 31'' x 21 1/4''
Net Weight
23.000 lbs
Minimum distance from counter front (in)
1 7/8''
Minimum distance from rear wall (in)
3''
Location of heating element
front left
Power of heating element (kW)
1 kW
Type of heating element
Gas
Location of 2nd heating element
center left
Location of 3rd heating element
back left
Power of 3rd heating element (kW)
1.75 kW
Type of 3rd heating element
Gas
Location of 4th heating element
middle back
Location of 5th heating element
back right
Power of 5th heating element (kW)
3 kW
Type of 5th heating element
Gas
Location of 6th heating element
center right
Location of 7th heating element
front right
Power of 7th heating element (kW)
1.75 kW
Type of 7th heating element
Gas
Location of 8th heating element
front middle / central
Location of 9th heating element
front centre/cent
Residual Heat Indicator
Separate
Type of safety device for gas
Electromagnetic for each burner
Safety
SMARTFLAME
Total connected gas load
12,500 W
Location of gas connection
Bottom, Rear, Right
Frequency
60 Hz
Energy source
Gas
Power Cord Length
40''
Watts
360 W
Included Accessories
1 x nozzle set for liquid gas, 3 x cast iron pan support
GTIN
04242005232468
EAN
4242005232468
Sleek Knobs with LED Indicators
Simmer delicate sauces with the OptiSim(R) Burner
Boil water quickly with a Dual-Flame Power Burner
Eliminate the guesswork of cooking with FlameSelect(R)
Easy to clean, low-profile design
Dishwasher-safe grates
