PRODUCT DESCRIPTION
Hood does not have an option for hood extensions. The do have 3 height options.
Hood Width x Depth x Height
36"W x 24"D x 30"H, 42"H or 54"H (600 cfm/8" collar)
48"W x 24"D x 30"H, 42"H or 54"H (1200 cfm/10" collar)
Specifications
Electrical Volts
120V
Heat Sensor
No
Installation Type
Wall Mount
Sabbath Mode
No
Product Depth
24.00 Inch
Primary Energy Type
Electric
Number of Electrical Plugs
1
Product Weight
172.00 Pound
Universal Product Code (UPC)
767459003869
Global Trade Item Number (GTIN)
767459003869
Product Series Title
Loge
Removable Grease Filter
Yes
Primary Warranty Short Description
2 Years Parts and Labor
Star K Certified
No
Ship Width
30.00 Inch
Recirculating Kit
No
Residential or Commercial Product
Residential Use
Heat Lamps
No
Brand
AGA
Selling Unit
Each
Product Width
48.00 Inch
Product Dimensions (WxDxH)
48 Inch X 24 Inch X 54 Inch
Minimum Installation Height Above Cooktop
30.00 Inch
Product Height
54.00 Inch
Electrical Phase
1PH
Ship Method
LTL Common Carrier
Product or Accessory
Product
Outdoor or Indoor Use
Indoor Only
Maximum Installation Height Above Cooktop
36.00 Inch
Exterior Trim Finish Color
Brushed Brass
Dishwasher Safe Filter
Yes
Exterior Finish Color
Stainless Steel
Ship Weight
225.00 Pound
Exhaust Duct Width
8.0 Inch
Freight Class (NMFC)
70
Air Movement CFM
1200.00 Cubic foot per minute
Control Type
Push Button
Electrical Connection Type
Cord and Plug
Electrical Total Amperage
5.40 Ampere
Prop 65 Warning
WARNING: This product can expose you to chemicals including lead, which are known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information, go to www.p65warnings.ca.gov.
Countries Certified for Sale
Canada, United States
Dedicated Circuit Required
No
Ship Depth
54.00 Inch
Remote Control
No
Energy Star Certified
No
Electrical Plug Type
NEMA 5-15
Number of Fan Speeds
3
Professional Installation Required
Yes
Electrical Hertz
60.00 Hertz
Number of Lights
3
Number of Ducts
1
Fan Motor Location
Internal
Exhaust Duct Run Maximum
35.00 Feet
Model
AH4854LGE-SS-BB
Hood Type
Wall Hood
Ship Height
66.00 Inch
Country of Origin
United States (USA)
Bright LED lighting offers natural looking, 3000K color spectrum. The 36" hood features 2 lights, the 48" hood features 3 lights.
Large 3 speed blower operates at lower RPM reducing the sound level.
Dishwasher safe, commercial style baffle filters for effectively removing airborne contaminants. Detergent inlet holes and grease exit holes in baffle filters for superior dishwasher cleaning.
Electronic touch controls for 3 speed blower and LED lights.
LED light bulbs draw only 6 watts each and energy efficient motors draw only 2.5 amps.
Mounting bars at top and bottom allow for attaching to stud supports. Open top and back design for centered duct location or offset top duct and/or rear offset discharge.
