PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Wall
Vent Type
Ducted
UPC
646328011115
GTIN
00646328011115
Country of Origin
Taiwan
Model Group
ZSP-C
Model Name
Siena Pro Wall
Collection
Core Collection
Replacement Model
ZSP-E48DS
Blower Included
Yes
Blower CFM w/ACT
590, 390
Internal Blower 1 CFM
1200
Internal Blower 1 Min. Sones
3.5
Internal Blower 1 Max Sones
9
Minimum CFM
450
Installation Type
Wall
For Outdoor Use
No
Color
Stainless Steel
Controls Type
ICON Touch(R)
Blower Speeds
5
Automatic Delay-Off
Yes
Clean Air Function
No
Lighting Type
LED
Lights Quantity
2
Watts Per Bulb
6
Lights Levels
2
Grease Filter Type
Hybrid Baffle
Compatible Mesh or Baffle Filter Part Number
50210041
Duct Discharge
Vertical
Duct Size; Horizontal; IN
N/A
Duct Size; Vertical; IN
10
Mounting Height Above Cooktop; IN
24 - 34
Voltage
120
Maximum Amperage
9
ADA Compliant
Yes, with optional remote
Warranty Parts / Labor
3 / 1
Compatible Appliances
Z1C-00SP, MUA010A, AK1718, RC-0002
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
Yes
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
Primary Material
Stainless Steel
Wattage
1080
Certification
UL
Nominal Width; IN
48
Net Width; IN
47.875
Net Depth; IN
21.9375
Net Height; IN
27.5 - 42
Weight; LBS
64.5
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
9 ft.
Chimney Height in.
16
Chimney Width in.
16.68
Chimney Depth in.
12.18
Shipping Length; IN
18.2
Shipping Width; IN
53.3
Shipping Height; IN
28.9
Shipping Weight; LBS
75.5
Shipping Method
LTL
Freight Class
300
Certification #
E127334
Duct Type
Vertical
GTIN
00646328011115
EAN
0646328011115
UPC
646328011115
ICON Touch(R) Controls
LumiLight LED Lighting
Hybrid baffle filters
Dual-Level Lighting
Powerful 1200-CFM Blowers
Optional Extension Duct Cover Kit
Optional Make-Up Air Kit
