PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Island
Vent Type
Ducted
UPC
646328011085
GTIN
00646328011085
Country of Origin
Taiwan
Model Group
ZSL-C
Model Name
Siena Pro Island
Collection
Core Collection
Replacement Model
ZSL-E48DS
Blower Included
Yes
Blower CFM w/ACT
590, 390
Internal Blower 1 CFM
1200
Internal Blower 1 Min. Sones
3.5
Internal Blower 1 Max Sones
9
Minimum CFM
390
Installation Type
Island
For Outdoor Use
No
Color
Stainless Steel
Controls Type
ICON Touch(R)
Blower Speeds
5
Automatic Delay-Off
Yes
Clean Air Function
No
Lighting Type
LED
Lights Quantity
4
Watts Per Bulb
6
Lights Levels
2
Grease Filter Type
Hybrid Baffle
Compatible Mesh or Baffle Filter Part Number
50200050
Duct Discharge
Vertical
Duct Size; Horizontal; IN
N/A
Duct Size; Vertical; IN
10
Mounting Height Above Cooktop; IN
24 - 34
Voltage
120
Maximum Amperage
8
ADA Compliant
Yes, with optional remote
Warranty Parts / Labor
3 / 1
Compatible Appliances
Z1C-01SL, MUA010A, RC-0002
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
Yes
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
Primary Material
Stainless Steel
Wattage
960
Certification
UL
Nominal Width; IN
48
Net Width; IN
48.875
Net Depth; IN
28
Net Height; IN
32.5
Weight; LBS
122
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
9 ft.
Chimney Height in.
32.5
Chimney Width in.
15.6875
Chimney Depth in.
11.9375
Shipping Length; IN
32.3
Shipping Width; IN
52.2
Shipping Height; IN
31.9
Shipping Weight; LBS
126.3
Shipping Method
LTL
Freight Class
250
Certification #
E127334
Clean Filter Alert
Yes
Duct Type
Vertical
GTIN
00646328011085
EAN
0646328011085
UPC
646328011085
Airflow Control Technology(TM) (ACT(TM))
ICON Touch(R) Controls
LumiLight LED Lighting
Dual-Level Lighting
Quick-Lock Installation System
Hybrid Baffle Filters
Optional Extension Duct Cover Kit
