PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Wall
Vent Type
Convertible
UPC
646328011054
GTIN
00646328011054
Country of Origin
Taiwan
Model Group
ZSI-C
Model Name
Siena Wall
Collection
Core Collection
Replacement Model
ZSI-E30DS
Blower Included
Yes
Blower CFM w/ACT
390, 290
Internal Blower 1 CFM
650
Internal Blower 1 Min. Sones
1
Internal Blower 1 Max Sones
6
Minimum CFM
200
Installation Type
Wall
For Outdoor Use
No
Color
Stainless Steel
Controls Type
ICON Touch(R)
Blower Speeds
5
Automatic Delay-Off
Yes
Clean Air Function
No
Lighting Type
LED
Lights Quantity
2
Watts Per Bulb
6
Lights Levels
2
Grease Filter Type
Hybrid Baffle
Compatible Mesh or Baffle Filter Part Number
50210041
Duct Discharge
Vertical or Horizontal
Duct Size; Horizontal; IN
8, 3.25 x 10
Duct Size; Vertical; IN
8
Mounting Height Above Cooktop; IN
26 - 34
Voltage
120
Maximum Amperage
4
ADA Compliant
Yes, with optional remote
Warranty Parts / Labor
3 / 1
Compatible Appliances
ZRC-00SI, Z1C-00SI, MUA008A, AK1710, Z0F-C091, RC-0002
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
Yes
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
Primary Material
Stainless Steel
Wattage
480
Certification
UL
Nominal Width; IN
30
Net Width; IN
29.9375
Net Depth; IN
21.9375
Net Height; IN
27.5 - 42
Weight; LBS
38.1
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
9 ft.
Chimney Height in.
15
Chimney Width in.
10.5
Chimney Depth in.
8.43
Shipping Length; IN
18.3
Shipping Width; IN
35.75
Shipping Height; IN
29.2
Shipping Weight; LBS
50
Shipping Method
Small Parcel
Freight Class
300
Certification #
E127334
Duct Type
Vertical
GTIN
00646328011054
EAN
0646328011054
UPC
646328011054
