PRODUCT DESCRIPTION
Easy to maintain and service
Removes 20%-35% more moisture from the air than standard Zoneline air conditioners* (*Varies when comparing dehumidification rates of the 7,000/9,000/12,000 BTU base models to their dry air model counterparts)
11,000 BTU
11.0 EER
4.2 pints/hour
360/270
47
Baked-on mastic sound barrier, cross flow blower and two DC fan motors create less noise to ensure comfort
Extends life of the unit in sea coast areas/corrosive environments
Keeps the room from overheating or freezing
Prevents expensive over-cooling or over-heating of the room
Features
Quiet operation
Baked-on mastic sound barrier, cross flow blower and two DC fan motors create less noise to ensure comfort
Simplified structure
Easy to maintain and service
Energy efficiency
11.0 EER
Specifications
Cooling BTUH (MIN)
10900.0 Btu
Cooling EER (BTUH / Watt)
11.0
CFM Indoor Fan High
360
CFM Indoor Fan Low
270
Dehumidification (pts./hr.)
4.2
Vent CFM (high fan at zero ESP)
44
Corrosion Treated
Yes
Discharge Grille
2-position
Electronic Micro Computer Control
Yes
Fan Cycle Switch
Yes
Fan Motor
2
Fan Speed Control
Yes
Fan Speed Selections
Hi/Low CoolingHi/Low Fan OnlyHi/Low Heating
Filter Type
Rigid FrameSlide-Out
Heat - Cool
Yes
Louver Style
Reversible
Manual Vent Control
Hidden
Rotary Compressor
Yes
Temperature Limiting
Electronic 7-Step
Vent Control
3-position
Dry Air
Yes
Venting Features
Concealed Manual Vent ControlOutdoor Vent Control - 3 PositionsVent Air Filter
Zoneline Features
Remote Thermostat CompatibilityUniversal HeatersWeather Protected Electrical ComponentsAuto Power RecoveryAutomatic Indoor Frost ControlCentral Desk Control CompatibilityFreeze SentinelHeat SentinelPower Cord (LDCI) includedProportional - Integral ID AirflowRandom Twist/Length Segment Tangential Blower
Heating System
Electric Resistance
Product Type
Packaged Terminal Air Conditioners (PTAC)
Temperature Range
60 - 85 F
Sensible Heat Ratio
54%
Chassis Type
Slide-In
Control Type
Coverless Backlit White LED Touch Controls
R-410A refrigerant
SMC base pan
Simplified structure
Perfect for high humidity climates
Cooling capacity
Energy efficiency
Dehumidification
Indoor fan CFM (high/low)
Fresh air vent CFM (fully open high fan)
Quiet operation
Corrosion resistant
Electronic temperature limiting
Electronic touch controls with LED display
Cooling - Amperes; F.L. - Cooling
3.9
Cooling - Amperes; L.R.
23.5
Cooling - Watts
990
Power Factor
97
Voltage (MAX)
265.0 V
Parts Warranty
Limited 1-year entire applianceLimited 5-year sealed refrigerating system
Labor Warranty
Limited 1-year entire applianceLimited 5-year sealed refrigerating system
Warranty Notes
See written warranty for full details
Net Weight
110.0 lb
Overall Depth
20.8125 in
Overall Height
16.0 in
Overall Width
42.0 in
Net Weight
110.0 lb
Overall Depth
20.8125 in
Overall Height
16.0 in
Overall Width
42.0 in
