PRODUCT DESCRIPTION
Specifications
Cooling BTUH (MAX)
10000 Btu
Cooling EER (BTUH / Watt)
10.6
Dehumidification (pts./hr.)
2.7/2.7
Cooling BTUH (MIN)
9800 Btu
Installation
Wall Mounted
Color Appearance
White
Warranty Notes
See written warranty for full details
Labor Warranty
Limited 2-year entire appliance Limited 5-year sealed refrigerating system
Parts Warranty
Limited 2-year entire appliance Limited 5-year sealed refrigerating system
Volts/Hertz
230V-208V/60Hz
Cooling - Rated Cooling Amps AHAM
4.3/4.7
Cooling - Watts
940/920
Voltage/Hertz/Phase
230-208/60/1
Voltage (MIN)
208 V
CEER
10.6
Voltage (MAX)
230 V
Wall Case
RAB46/47/48/26 Required At Additional Cost
Overall Width
26 in
Approximate Shipping Weight
83.1 lb
Depth to Louvers
5 in
Overall Height (Excludes Sleeve)
14.875 in
Overall Height
15.625 in
Overall Depth (Excludes Sleeve)
19.90625 in
Overall Depth
21.8125 in
Overall Width (Excludes Sleeve)
24.8125 in
Net Weight
83.1 lb
Louver Style
6-Way
Control Type
Electronic
Fan Speed Selections
3 Cooling 3 Fan Only
Optional Grill
RAG13/RAG13A/RAG14E
Product Type
Built-In
Refrigerant Type
R410A
Air Discharge
Over / Under
Filter Type
Rigid Tilt-Out Washable
Style
Thru-Wall
Chassis Type
Slide-In
Plug Type
Tandem/Right Angle/LCDI
WiFi Connect
Built-In
Remote Control
Yes
Thermostat Type
Electronic Digital
Temperature Range
60->85 F
Cord Length
68"
Airflow (cfm) Roomside (hi/low)
280/260/240, 270/250/230
Rotary Compressor
Yes
Outdoor Vent / Exhaust
Yes
Unit Type
Cool Only
Room Air Conditioner Features
Batteries Included Energy Saver Filter Reminder Function Remote Control Smart Fan Switch
GTIN
00084691864356
EAN
0084691864356
UPC
084691864356
