PRODUCT DESCRIPTION
Features
Telescopic rails
ASKO uses telescopic guide rails with ball bearings to make the racks glide smoothly and quietly. For easy loading and unloading, you can also take out the whole rack.
XL dishwashers
Our XL dishwashers have a loading height of 21-1/4". Combined with the smart four level rack system the load is 40% more, with countless possibilities to make it all fit in.
Top cutlery tray
The top tray for cutlery and kitchen utensils is easy to remove for easy unloading. With a width of 12-3/4" the centred tray leaves plenty of room for tall wine glasses in the upper rack on each side of the tray. And with the Instant Lift(TM) you have the freedom to adjust the upper rack to be 1-1/2" or 2-1/4".
Aqua Safe(TM) system
Do you hesitate to leave the dishwasher on while you are not at home? Aqua Safe(TM) system is an advanced safety system which ensures a leak-safe dishwasher day and night.
Flexiracks(TM)
ASKO Flexiracks(TM) from sturdy, nylon coated steel and are easily adjustable in different heights depending on which type of load you have.
Instant Lift(TM)
Our InstantLift(TM) height adjustment system, allows for freeing up between 1-1/2" or 2-1/4" in the upper rack,. A simple and flexible way to make room for it all.
Super Cleaning System(TM) (SCS(TM))
Rinse the dishes. Clean the interior, including the filter. Choose the best program. How many steps is that? One - and we call it the Super Cleaning System - or our best invention.
8 Steel(TM)
8 Steel(TM) - more steel less plasticNo other material lasts as long as steel. And no other dishwashers have as many details made from steel instead of plastic as ASKO dishwashers. In fact, eight of the most important components in our dishwashers are made of high-quality steel rather than plastic: the container, loading racks, spray pipe, spray arms, strainers, outer base, feet, and inner door. By using more steel and less plastic, we make our machines last longer.
Wide Spray(TM)
WideSpray(TM) which creates a high-pressure jet spray in combination with a wide spraying nozzle. The pots and pans becomes clean and you get time to widen your scope.
16 - Loading capacity
The world s biggest load capacity. The latest addition to our rack system is a flexible top cutlery tray with its own spray arm and space for sixteen sets of cutlery, small bowls, or other utensils that can be difficult to load. The width of the top cutlery tray has been optimised to make room for tall glasses in the upper rack and, if more space is needed simply take the top cutlery tray out.
Knife holders
Knives are sensitive things, so too are fingers. That is why we have done everything possible to protect both as best we can. Our knife holder is extra deep so that the blades remain steady throughout the wash cycle. There are knife holders on three levels: in the middle basket, in the upper basket and in the top basket. We guarantee a clean cut.
Brushless motor
A brushless motor is not only quieter and more reliable. It also consumes less energy. You want your dishwasher to work forever. So do we.
Touch Proof(TM)
The ultra-thin, transparent TouchProof(TM) coating protects your dishwasher stains and grease Easy to clean, scratch resistant it will keep your dishwasher looking brand new year after year.
Turbo Drying(TM)
The Turbo Drying(TM) system mixes dry air from outside the machine with the moist air inside. This feature also is available for fully integrated machines. We promise, you ll be a great fan.
Jet Spray(TM)
Our JetSpray(TM) nozzle for tall, narrow objects like baby bottles, vases and bottles is combined with a special holder that makes sure that the cleaning result is perfect.
Crystal Glass
Wash fragile items made of crystal/glass, such as crystal glass from Orrefors, using the gentle dishwashing program Crystal glass.
3 Level rack
ASKO s three level rack system allows you to optimize the load. Remove, adjust, fold and move the racks, pin rows and cutlery rack to meet your every need.
20 years
Dishwashers designed to last for 20 yearsToday, sustainability and responsibility go hand in hand. So when we design our products, it is our responsibility to not only make products that last, but which also make things better - for our customers and for the planet. We develop our dishwashers responsibly and design them to make a difference. To ensure that they can do so for a long time, we test them equivalent to 20 years of lifetime.
Specifications
8 Steel(TM) - Vital parts of the dishwasher made in stainless steel
Yes
No need to rinse the dishes thanks to Super Cleaning System(TM)
Yes
Automatic water-softener for better washing performance
No
Number of spray arms
3 pcs
Cleaning systems
Jet Spray(TM) - Extra dishwashing power for vases, bottles and baby bottles Wide Spray(TM) - Extra dishwashing power for pots and pans Cutlery Spray(TM) - Extra dishwashing power for the cutlery basket No need to rinse the dishes thanks to Super Cleaning System(TM) Aqua Level(TM) Sensor Stainless steel spray arms
Exterior handle
Number of place settings
16 pcs
Number of racks
3
Top tray
Easy height adjustment With rack for knives and utens With rack for bowls and cups With telescopic rails Handle Removable
Upper rack type
Premium, fixed tines and foldable wine shelves
Upper basket system
Easy height adjustable with lever
Upper basket
Perfect ergonomy with easy sliding telescopic rails Standard knife stand Fixed glass support Fixed pin rows Right foldable wine shelf with utensil rack Foldable wine shelves to right Foldable wine shelves to left Handle with ASKO logo Handle Small distance between the basket threads - makes loading easy and prevents small items to fall through
Middle basket
Without middle basket
Lower rack type
Premium - Basket wiring in steel, fixed pin rows and removable cutlery basket
Lower rack
Cutlery basket Foldable/divisible rear pin row Handle with ASKO logo Handle Small distance between the basket threads - makes loading easy and prevents small items to fall through.
Automatic dosing system
No
Interior light
No
Possible to control via Wi-Fi
No
Type of display
LCD display
Status Light(TM) - Visual indication of dishwashing progress
No
Remaining time indication
Yes
Wash end indication
Sound signal
Language settings
Chinese simpified Chinese traditional Swedish Slovenian Russian Portuguese Polish Norwegian Dutch Latvian Lithuanian Japanese Italian Croatian French Finnish Estonian Spanish English German Danish
Programs
Sanitize Light wash Self cleaning Crystal glass Lower half Upper half Rinse and hold programme Plastic wash Time program ECO wash Standard
Delayed start
Possible to delay up to 24 hours
Options and modes
Intensive mode - The dishwasher uses more heat and water. The program time is extended Night mode - Lower noise level. The program time is extended. Speed mode - The program time is shortened. More energy is used. Green mode - Less energy and water is used. The program time is extended Time set Super Rinse(TM) - Two extra rinses Extra dry - Improves the drying result
From the front adjustable door spring
No
From front adjustable rear foot
Yes
Installation
Multi fit outlet hose Integrated anti-siphon - Prevents spontaneous in- and outlet of water and simplifies elevated installation Trim kit Steam protection strip
Sliding door
No
Possible to install elevated
Yes
Min. niche width
24 ''
Min. niche height
32 5/16 ''
Depth (incl. wall spacing)
22 1/16 ''
Height setting
1 15/16 ''
Adjustable kick plate
No
Aqua Safe(TM)
Anti Block(TM) - Self cleaning drain pump Light and sound alarm Maximum time for water intake Extra durable PEX inlet hose Stand-by water protecion - Leakage detection when machine is off Aqua Level(TM) Sensor - Ensures an optimized water level Aqua Detect(TM) - Instant recognition of any leakage in the motor compartment Detection of water leakage on the bottom plate Waterproof bottom plate Extra durable stainless steel container Sealing points outside container
Aqua Safe(TM) system
Yes
Child safety
Kid Safe(TM) - Lockable controls
Indication of low level of rinse-aid
Notification in display
Water connection
Hot&cold water
Adapter for water connection
No
Max. temperature of inflow water
140 (degree)F
Noise level (max)
42 dB(A)
Reference programme
1
Estimated yearly energy consumption
235 kWh
Energy consumption - normal program
1 kWh
Estimated annual water consumption
687.4 gal
Water consumption
3.2 gal
Power consumption in standby mode
0.49 W
Consumption in off mode
0.49 W
Plug type
USA
Connected load
1300 W
Voltage (V)
120 V
Number of phases
1
Fuse
15 A
Frequency
60 Hz
Required inlet water pressure psi
0,03-1
Net weight
93.7 lb
Width
24 ''
Height
32 11/16 ''
Depth
22 ''
Maximum product height
34 11/16 ''
Length of electrical cord
47 1/4 ''
Depth with door open
47 3/16 ''
Length inlet hose
64 3/16 ''
Length outlet hose
90 9/16 ''
Packaging width
25 3/16 ''
Packaging height
35 1/16 ''
Packaging depth
26 3/4 ''
Gross weight
101 lb
Product code
737061
EAN code
3838782510380
Noise level (max)
42 dB(A)
Number of place settings
16 pcs
Number of racks
3
Upper rack type
Premium, fixed tines and foldable wine shelves
Size
XL
Automatic dosing system
No
Installation
Built-in
Series
Style
Noise level (max)
42 dB(A)
Number of place settings
16 pcs
Number of racks
3
Upper rack type
Premium, fixed tines and foldable wine shelves
Size
XL
Automatic dosing system
No
Installation
Built-in
Series
Style
GTIN
03838782510380
EAN
3838782510380
